SOMFY animeo KNX Master Control W8 Gebrauchsanweisung Seite 6

EN
A
PICTURES
[1] KNX Master Control W8
[2] KNX Master Control W2
B
MOUNTING
Choose the optimal location: flat and large surface.
[1] Installation and distance measures
C
WIRING
[1] Keep the minimum distance
[2] Tool for all terminals
D
WIRING DIAGRAM
[1] KNX Master Control W8
[2] KNX Master Control W2
For further information please follow our
detailed installation guide (www.somfy.com)
We care about our environment. Do not
dispose of the appliance with usual house-
hold waste. Give it to an approved collection
point for recycling.
E
STATUS INDICATION
[1] Fieldbus controller TCP/IP 750-891
LED Color Meaning
LINK indicates a connection to the physical network
1
green
ACT at port 1
LINK indicates a connection to the physical network
2 green
ACT at port 2
MS red/green indicates the status of the node
NS red/green indicates the network status
red/green/ indicates the operation of the node and signals via
I/O
orange a blink code faults encountered
indicates information to the internal bus faults,
red/green/
USR controlled from the user programm according to
orange
the visualization programming
indicates the status of the operating voltage -
A green
system
indicates the status of the operating voltage -
B green
power jumper contacts
[2] 2 Channel Up/Down Counter 750-638
Chan- Desig- Sta-
LED Function
nel nation te
A 1 Func- off Counter 1: no communication
green tion with coupler/controller
DI 1
on Counter 1: communication with
coupler/controller
B Status off Counter 1: csignal input off
green DI 1
on Counter 1: DC 24 V signal input on
C 2 Func- off Counter 2: no communication
green tion with coupler/controller
DI 2
on Counter 2: no communication
with coupler/controller
D Status off Counter 2: signal input off
green DI 2
on Counter 2: DC 24 V signal input on
[3] RS485 Interface 750-653
LED Channel State Function
A Function off No operational readiness or the
green internal data bus communication is
interrupted
on Operational readiness and troublefree
internal data bus communication
B T x D off Signal transmission TxD running
1)
green
on No signal transmission TxD
D R x D off Signal transmission RxD running
1)
green
on No signal transmission RxD
The pulses are very short and therefore the off status is difficult to recognise.
1)
[4] KNX/EIB/TP1 Terminal 753-646
LED Name State Function
A Router mode off Operating mode router not active
green
on Operating mode router active
flashing Synchronization
B KNX pro- off KNX programming mode not active
red gramming
on KNX programming mode active
mode
flashing Checksum error
C Data transfer off Internal data bus data transfer not
green module bus active
flashing Internal data bus data transfer active
D Data transfer off KNX data transfer not active
yellow KNX
flashing KNX data transfer active
E Device mode on Device mode active
green
off Device mode not active
flashing Synchronization
F Buffer off No buffer overflow
red overflow
on Overflow
G Internal fault off No fault
red
on • Checksum error
• Device not configured
H KNX bus off KNX bus voltage not available
green voltage
on KNX bus voltage available
