Watch the Building Tutorial On Our Website
If you are building the keyboard for the first time, we highly recommend you to watch the
building tutorial video on our website first, then start building the keyboard yourself.
Factory Reset
Troubleshooting? Don't know what's going on with the keyboard?
1. Plug in the power cable and switch the keyboard to Cable mode.
2. Factory reset the keyboard by pressing fn + J + Z (for 4 seconds)
3. Download the right firmware and QMK Toolbox from our website.
4. Switch the keyboard to OFF mode and remove the space bar keycap to find the
reset button on the PCB.
5. Hold the reset key first, then switch the keyboard to Cable mode.
Release the reset key, and the keyboard will now enter DFU mode.
6. Flash the firmware with QMK Toolbox.
7. Factory reset the keyboard again by pressing fn + J + Z (for 4 seconds)
Step by step guide can be found on our website.
K10 Pro Bluetooth Mechanical Keyboard Specifications
Number of keys
Switch type
Battery
Bluetooth working time (RGB)
Charging time
Charging port
Mode
Bluetooth operating distance
Name of Bluetooth device
Operating Environment
Technical specifications can be subjected to change without notice we apologize for any
inconvenience caused.
108
Mechanical
4000mAh
Up to 100 hours (Lowest brightness)
Around 3 hours
USB Type-C
Bluetooth / Wired
Within 10 meters (open space)
Keychron K10 Pro
-10 to 50°C
