FS UMC-GA1F1T Schnellstartanleitung Seite 9

LEDs
TP/LNK
SPD
FX/LNK
PWR
UMC-1S1T-R
LEDs
TP/LNK
SPD
8 EN
State Description
The link through the TP port is
Green
successfully established.
Blinking The TP port is actively sending or
Green receiving data.
O The TP port link is down.
Green
The TP port is operating at 1000M.
The TP port is operating at 10M/100M.
O
The link through the ber port is
Green
successfully established.
Blinking The ber port is actively sending or
Green receiving data.
O The ber port link is down.
Green The device is powered on.
TP/LNK
State Description
Green The TP Link is connected.
Blinking The TP port is actively sending or
Green receiving data.
Green The TP port is operating at 10G.
O The TP port is operating at 10M/1G.
SPD FX/LNK PWR
