rotary switch for
door release period
(no funktion in combi-
nation with the TS-Bus )
programming button
(no funktion in combi-
nation with the TS-Bus )
output voltage for
locking element
Pay attention to the
correct polarity!
Connection of fail-un-
locked door release
Pay attention to the
correct polarity
46
main board
switching voltage
max. 24V DC
switching current
max. 1A
door release
12 V-
-
+ relay
1 2 3 4 5 6
+
-
fail locked door release 1405/1405 RR
12 V-
door release
+
-
relay
1 2 3 4 5
- +
fail-unlocked door release 3405/3405 RR
keypad board
Fuse F 2
500 mAT
transformer
TSB
230 V AC
0V D
L1
bus
7 8 9
L1
external door release
push-button
6 7
sliding switch:
For permanent unlocking by means of
master code the sliding switch must be
I
in position II.
II
Code switch:
For standard use all switches
must be in position OFF.
In combination with the TS-Bus
switch 8 must be in position ON.
The switches 1-7 are used for
setting the participator adress .
N
earth terminal in the housing -
connect shield and earth lead
N PE
D00116-A0000202
