MIDI Optimizer DIM
Service
Maintenance
Attendance
• The lubricator requires a minimum of maintenance apart from cleaning.
• Do not refill above max. oil level indicator (upper sight glass)
Cleaning
There is no need to remove the lubricator from the compressed air line.
1. Turn the filler plug 90° counter clockwise and let out the compressed air
from the bowl.
2. When the bowl is depressurized, unscrew the bowl.
3. If the compressed air line is not shut off there should now be a small con-
tinuous air bleed from the internal of the housing.
4. Clean the bowl with water to which a little detergent has been added. Dry
thoroughly before refilling oil.
Lubrication
Oil refill
There is no need to remove the lubricator from the compressed air line.
1. Refill plug is closed and lubricator operational
EN
