Mounting instructions for waterpipe installers:
Important: Read these instructions thoroughly before
installing the appliance. Determine the precise position in the
salon with the salon owner and the installation specialist.
Caution:
•
The shampoo station is intended for operation in clean
and dry rooms at normal room temperature.
•
In the water supply system only original components
supplied by the manufacturer must be used.
•
The house installation must be equipped with a pressure
reducing valve. Recommended water pressure for the
shampoo station: approx. 3 – 5 bar.
•
The new set of hoses supplied with the unit must be
used. Old hoses must not be used.
•
Ensure that the height of the drain and installation
tunnel is correct.
1. We recommend to provide the supply lines with a
central shut-off device.
If the system is operated without a suitable shut-off
device, the angle valves must be closed at the end
of business hours.
2. Install the supply water and waste water lines as shown
in Fig. 3.
Mounting instructions for appliance fitters:
3. Detach the backrest cushion (1): (Fig. 1)
Pull the backrest upwards and remove.
4. Detach the seat body (2): (Fig. 1)
Only slacken the 4 wing screws (3) underneath the seat.
Remove the 2 hexagon socket bolts (4) (connection
between seat and frame). Detach the element
connecting the seat to the leg rest (6). Pull the seat
together with the armrests upwards.
5.
Prepare the cover section (7) for connection of the
installation tunnel:
Make sure that the mounting side corresponds to that
shown in the installation diagram!
Make 1 drilling Ø 80 mm and 3 drillings Ø 5,5 mm for
mounting brackets. (Fig. 2)
6.
Align the substructure (9) according to the installation
template and secure to the floor.
6 anchor bolts M 10 x 125 (extending 30 mm
above the finished floor) or metal plugs with metric
thread for hexagonal screws M 10 x 60.
7.
Secure the side cover sections (7) to the unit using
Velcro tape. Attach 2 mounting brackets for the
installation tunnel to both the side section (Fig. 2) and
wall (Fig. 3):
Fasten the mounting brackets on the top and front using
M5 screws + washers + nuts, fasten mounting brackets
on the rear only after the water installation.
Pure Basic MO W+R
GB
Mounting instructions for waterpipe installers:
8. Make sure that pipes/pressure hoses are parallel. Connect
the unit. Fit 40 mm dia. waste water pipe and R ½" pressure
lines with stop taps between the wall and unit. Prevent the
stop valves from turning while they are being
screwed on. Connect the waste water hose to the siphon
using a seal and union nut. Insert the waste water hose at
least 3 to 4 cm into the siphon. Connect the drain
bushing to the waste water hose using a hose clamp.
9. Close the mixing tap. Open the stop valve and check for
leaks with the mixing tap closed. Check the mixed water.
The hot water and cold water supply must correspond to
the coloured symbols on the mixing
tap.
10. Check the pressure of the unit with 8 bar water pressure.
Then set the pressure to 3 to 5 bar. On completion of the
installation work, always rinse out the water pipes. A central
regulating tap is required if more than one unit is installed.
This tap must be
easily accessible from the salon.
These mounting instructions apply to the connection
of one unit. If more than one unit is to be installed, the pipe
cross section must be increased accordingly.
Important: If the water pressure is above 5 bar, it must be
regulated by a pressure reduction valve.
Note for salon owners:
The connections described under points 1 to 2 and 8 to 10 must
be performed by the installer. The installer is responsible for any
problems that may occur. The manufacturer of the unit shall not
accept warranty claims for this work.
Mounting instructions for appliance fitters:
11. Fig. 2 + 3: Provide the installation tunnel (1) with rubber
edge protection (2) on both sides and put it onto mounting
brackets; to do this, push the tunnel diagonally onto the
mounting brackets from the rear and then align it vertically.
Fasten the mounting bracket on the rear of the tunnel from
the bottom oft he tunnel onto the shampoo station and the
wall.
12. Assembly: (Fig. 1)
Attach the seat body (2) to the frame and secure the seat
and frame using the 2 hexagon socket bolts (4).
Tighten the 4 wing screws (3) underneath the seat.
Secure the cover sections (7) to the frame (9) using Velcro
tape.
Loosely bind the 2 pressure hoses (hot + cold) and drain
hose together using cable ties.
Caution: The 3 hoses must not touch the frame (9) at any
point.
Secure the rear cover section (8) to the frame (9) using the
6 plastic screws.
Attach the element connecting the seat to the leg rest (6)
and fit the backrest cushion (1).
