4 - PRODUCT INSTALLATION

4.1 - Installation
Before starting the installation, make sure that the product is intact
and that the packaging contains all the components shown in Fig.3.
Make sure that the mounting area is compatible with the overall
dimensions (Fig.1).
Check the allowed opening angle according to the fixing points of the
brackets in Fig.4 and in the diagram in Fig.5.
Fig.6 is an example of a typical system:
- Operators (1)
- Photocells (2)
- Posts for photocells (3)
- Flashing light with integrated aerial (4)
- Key or digital switch (5)
Mounting
Measure the value C (Fig. 4) = distance between the rotation fulcrum
of the leaf and the pillar surface where the rear bracket will be fixed.
Move manually the leaf up to the opening required (maximum 120°):
establish the value of the maximum opening angle of each leaf.
Mark on the diagram in Fig.5 the value C and trace an horizontal
line up to intersect the area that includes the angle value measured
before.
Trace some vertical lines on the intersection points between the
horizontal line and the area in order to find the useful values for the
dimension A (fig. 4).
Chose the value A in this range.
Mark on the pillar the value A and trace a vertical line in
correspondence (Fig.7a).
4.2 - Adjusting the mechanical limit switch in opening
Unscrew the cover screws (Fig.15a). Raise the back by about 1 cm
then slide it out forwards (Fig.15b).
ATTENTION: the lights on the cover are connected by two
wires, disconnect the terminal or lay carefully the cover
upside-down on the external part (Fig.16).
Loosen the screw of the mechanical limit switches up to when they
can slide (Fig.12).
Release the gearmotor and open manually the leaf up to the
requested opening position.

4.3 - Electrical connections

Insert the supply cable (Fig.17). Connect the wires of the supply
cable to the terminal following the electrical drawing in Fig. 18.
Proceed with the other connections following the control unit's
4.4 - Mechanical and electronic connections of the second motor
In case of installation of the second motor, follow the above
mentioned instructions for the mechanical mounting, for the

4.5 - Replacing led

Switch-off the power supply.
Open the cover as shown on paragraph 4.2.
By using a screwdriver, release the bottom screw of the cover
(Fig.19a).
Remove the mask and pull out the led band (Fig.19b) .
Mounting the motor bracket to the pillar
Draw a horizontal line on the pillar in line where the leaf bracket
should be fixed (Fig.7b).
Center the pillar bracket with the vertical line and the horizontal line
previously traced by fixing the bracket using suitable screws and
washers (not supplied) (Fig.7c).
Fasten the motor to the pillar bracket with the two screws and nuts
supplied (Fig.8).
During this phase, make sure that the motor is perfectly aligned.
ATTENTION: an off-axis mounting can cause malfunctioning
and damage the automation system.
Mounting the motor bracket
Move the gate leaf up to the maximum opening position (Fig.9).
Release the gearmotor (Fig.10)
Place the arm close to the leaf and lay on the leaf the gate bracket;
holding with one hand the bracket in contact with the leaf, try to
make a complete opening and closing movement.
Fasten the gate bracket to the leaf with suited screws (not supplied)
(Fig.11a).
Fasten the motor arm to the bracket, by inserting the pin and the
corresponding safety ring (Fig.11b).
Important: make sure that the bracket and the gate arm are
perfectly aligned.
ATTENTION: a not aligned mounting can cause malfunctioning
and damage the automation system
Insert the pin completely into the first free hole close to the leaf
(Fig.13).
Move the mechanical stop up to the stop limit on the pin head
(Fig.14a) and screw again the mechanical stop (Fig.14b).
In order to adjust the stop in opening, move the leaf up to the
requested opening position and insert the pin into the first free
hole opposite to the leaf.
Move the mechanical stop on the stop limit on the pin head (Fig.14a)
and screw it again (Fig.14b).
instructions.
Replace the cover to its original position and fasten the two fixing
screws.
electrical connections refer to the Fig.21.
Disconnect the plug connector (Fig.20a).
Connect the new led stripe and insert them into the mask.
Insert the mask by placing first the seal side and then fastening it
with the screw (Fig.20b).
