2 - PRODUCT OVERVIEW

2.1 - Description of the product

The RÉVO gear motors are destined to be installed in systems for the
automation of gates with hinged doors.
The RÉVO gear motors have been designed and constructed to be
fitted onto hinged doors within the weight limits indicated in the
2.2 - Model and technical characteristics
Code
REVO2024
REVO2024S
REVO20110
REVO2224M
REVO2224S

TECHNICAL DATA

MODELS
TECHNICAL SPECIFICATIONS
Torque
Working cycle
Opening time at 90°
Control board
Power supply
Absorption
Engine power
Integrated lights
Degree of protection
Dimensions (L - P - H)
Weight
Operating temperature
Leaves maximum weight

3 - PRELIMINARY CHECKS

Before installing this product, verify and check the following steps:
- Check that the gate or door are suitable for automation
- The weight and size of the gate or door must be within the maxi-
mum permissible operating limits specified in Fig. 2
- Check the presence and strength of the security mechanical stops
of the gate or door
- Check that the mounting area of the product is not subject to flood-
ing
- Conditions of high acidity or salinity or proximity to heat sources
could cause malfunction of the product
- Extreme weather conditions (for example the presence of snow,
ice, high temperature range, high temperatures) may increase the
friction and therefore the force required for the handling and initial
starting point may be higher than under normal conditions.
10
Description
24 Vdc gear motor for hinged doors with max length 2,3 m or weight 250 Kg, 230 Vac
24 Vdc gear motor for hinged doors with max length 2,3 m or weight 250 Kg, without control unit
24 Vdc gear motor for hinged doors with max length 2,3 m or weight 250 Kg, 110 Vac
24 Vdc gear motor for hinged doors with max length 2,3 m or weight 250 Kg, 230 Vac
24 Vdc gear motor for hinged doors with max length 2,3 m or weight 250 Kg, 230 Vac
REVO2024
Nm 120
% 80
sec adjustable
14A
Vac (Vdc) 230 (24)
A 0,5
W 100
yes
IP 44
mm 120 - 250 - 350
Kg 10,5
°C -20°+55°
Kg 250
technical specifications table.
The use of gear motors for applications which differ from those
indicated above is prohibited.
REVO2024S REVO20110
120 120
80 80
adjustable adjustable
- 14A
(24) 110 (24)
2 1
40 100
yes yes
44 44
120 - 250 - 350 120 - 250 - 350
8 10,5
-20°+55° -20°+55°
250 250
- Check that the manual operation of gate or door is smooth and
friction-free and there is no risk of derailment of the same
- Check that the gate or door are in equilibrium and stationary if left
in any position
- Check that the power line to supply the product is equipped with
proper grounding safety and protected by a magnetothermal and
differential security device
- Provide the power system with a disconnecting device with a gap
of contacts enabling full disconnection under the conditions dictated
by the overvoltage category III.
- Ensure that all materials used for the installation comply with cur-
rent regulations
REVO2224M REVO2224S
120 120
80 80
adjustable adjustable
CT20224 CT20224
230 (24) (24)
0,5 2
80 40
- -
44 44
120 - 250 - 350 120 - 250 - 350
10,5 8
-20°+55° -20°+55°
250 250
