User Menu
TIME PROGRAM SERVICE TYPE SET
Sets the time schedule mode used by the device for heating
and cooling.
– "Two levels setpoint": the daily 2-level time scheduling
allows for dividing the schedule into a maximum of 4 com-
fort slots and 4 reduced-temperature slots within the 24
hours of each day. It is possible to define a temperature
set-point for the comfort slot and one for the reduced-tem-
perature slot.
– "Multilevel setpoint": in daily multi-level time schedul-
ing, available only on specially configured products, it is
possible to define up to 12 daily slots, each of which can be
associated with a specific set-point temperature.
Advanced settings
Cooling settings
AUTO function
System measurement unit
Time Program mode
Room temperature correction
Zones selection
ROOM TEMP CORRECTION
This parameter allows for correcting the room temperature
measured by the device by ±5°C.
SELECT THE ZONES TO MANAGE
In this page you can select the hydraulic zones to be displayed
in the "Zones management" menu.
Select the zones to manage
Zone 1
Zone 2
Zone 3
Zone 4
Two levels setpoint
Multilevel setpoint
Fig. 73
Zone 5
Zone 6
All zones
Save
Fig. 74
Errors and diagnostic messages
10°
Error 910
HP communication error
Heat Pump TDM
Call the technical service
Error 910 - HP communication error
Diagnostic events (errors, alert messages, etc.) are shown in a
pop-up window in the home page.
The pop-up window shows the following information:
– Error code
– Error description
– Device/product that generated the error
– Any actions to be implemented for solving the problem
The pop-up window can be closed by pressing the Back but-
ton . The error notification will remain visible in the home
page where the error icon
are displayed.
The window with the detailed information will automatically
pop up again after one minute. It can also be opened manu-
ally by pressing the Back button
Fr 4-JUN 12:30
Fig. 75
, the error code and description
again.
