MAINTENANCE
The control panel needs no particular maintenance. To ensure optimum performance from the equipment,
once a year check the cables and the electrical connections.
Clean the control panel with a soft cloth dampened with water. Do not use chemical or abrasive products
to clean the control panel.
TECHNICAL DATA
MODEL
OUTPUT CHARACTERISTICS
Current capacity of right or left thruster
commands.
INPUT CHARACTERISTICS
Supply voltage (1)
Quiescent current (2)
Maximum current absorption (3)
AMBIENT CHARACTERISTICS
Operating temperature
Protection rating (4)
GENERAL CHARACTERISTICS
Dimensions including frame (L x L)
Weight
EMC class
(1)
With power supply voltage less than 8 Vdc the control panel can reset.
(2)
Typical value with control panel disabled.
(3)
Typical value with control panel enabled and one direction button pressed.
(4)
Excluding the back of the control panel (IP20).
®
QUICK RESERVES THE RIGHT TO MODIFY THE TECHNICAL CHARACTERISTICS OF THE EQUIPMENT AND THE CONTENTS OF THIS MANUAL WITHOUT PRIOR NOTICE.
TCD1022/1042 - REV003B
MAINTENANCE - TECHNICAL DATA
TCD 1022
78 mm x 78 mm
80 g
4A max
from 8 to 30 Vdc
10 mA
55 mA +
absorption of remote control coil
from -20 to +70 °C
IP 66
EN 60945 - FCC Part 15 Rules 47
GB
TCD 1042
78 mm x 78 mm
140 g
