Operation
Placement of the Power Supply
Place the power supply at least 3.6 meters / 11.8 feet from the pool and
at least 12 cm above ground. CAUTION: The power supply is not water
Please use as much cable as
needed. Leave the remaining
resistant; it must not be exposed to water or to direct sunlight.
cable out of the pool.
Press the plastic snap on the zip ties in order to release the floating cable.
Use as much cable as needed in the water.
Before placing the cleaner unit in the water
Make sure there are no people in the pool. Make sure that the filters are
clean. Make sure the pool conditions are met; (see "Operating Conditions").
You may turn on
the cleaner when it
Placing cleaner in the water
reaches the floor.
Unroll the floating cable. It is recommended to extend a length of cable
that is equal to the diagonal size of the pool plus an additional two meters.
Smooth out coils or twists in the cable. Connect the floating cable to the
socket located on the power supply. Roll extra cable, not in the pool, near
the power supply. Place the robotic cleaner in the pool. Let it sink to the
3.6 m / 11.8 ft bottom of the pool. Do not start operation before the robotic cleaner is
settled on the pool floor. CAUTION: Operating the cleaner out of water
12 cm / 4.7 inch may cause immediate and severe damage resulting in loss of warranty.
above ground
Starting the robotic cleaner
Connect the power supply to the wall socket. The on/off button will light
up and the robotic cleaner will start its cleaning program. If the power
supply is already connected to the wall socket, the on/off button will flash
NO SWIMMING to indicate that the robotic cleaner is in standby mode. Press the On/Off
WHILE THE ROBOT
button in order to change the above mode (On to Off – standby, or vice
IS IN THE POOL
versa). Note: if the full filter indication light is ON make sure to remove and
clean the filter prior to putting the cleaner inside the pool water.
4
COSMY 100 / 150 / 200 / 250 ROBOTIC POOL CLEANERS
Operation
Cleaning cycle
During the cleaning cycle, the cleaner: moves across the pool floor picking up dirt and
debris. Changes direction and rotates automatically according to the selected program.
Climbs the pool walls every few minutes, as set in its internal program. Note: The robotic
cleaner might occasionally stop moving for a few seconds. This is part of normal
operation, not a malfunction.
Stopping robotic cleaner operation
The robotic cleaner moves automatically to 'standby' after every cleaning cycle and the
on/off button starts flashing. To stop the cleaner operation during a cleaning cycle, press
the operation button once. On/off button starts flashing and the cleaner is in standby
mode.
Pulling cleaner unit out of the water
(1) Unplug the floating cable from the power supply. (2) Pull the floating cable until the
unit is close enough to reach the handle. (3) Using the handle, lift the cleaner out of the
pool. CAUTION: Do not use the floating cable to lift the cleaner out of the water.
The power supply is connected to the robotic
cleaner via the floating cable (1). The unit is
powered by AC power (2) and supplies low voltage
2
and commands to the robotic cleaner through the
outlet socket.
The power supplies feature a control panel with
indicators:
a. On/Off (all models)
b. Full filter indicator (models 200 & 250 only)
c. Bluetooth indicator (models 200 & 250 only)
Power Supply
On/Off
COSMY 100 / 150
On/Off
Full filter
indicator
Bluetooth
COSMY 200 / 250
5
