1. Charging the Battery
Connect the charger to electric supply
(100-240V~AC, 50/60Hz).
Socket
Bottom of the
Adapte
Charging stand
Charging
Charging Finished
Charging Stand
and Battery
2. Changing the Battery
click
Open the battery cover
Insert the battery
into the compartment
3. Operation
Left Start Button
Right Start Button
Multi-function
Switch
Item
Operation
Diagram
Notes
1. Speed is set on
Push and keep
1s
"FREE" by default.
Switch
the multi-function
2. Default switch-on
On
switch for 1
gesture is "LR"
second
Push and keep
3s
Switch
the multi-function
Off
switch for 3
second
Dual
Push down the
Hand
start buttons with
Operation
both hands
Push and
1."FREE"→ "SPORT"→
Quickly turn
immediately
the switch
"TURBO"→"FREE"
Speed
release the
2. When battery drops
Switch 1
multi-function
below 50%: "FREE" →
switch
"SPORT"→"FREE"*
1. Push down the
start buttons with
both hands and
1. "FREE"→"SPORT"→
"TURBO"→"FREE"
keep the device
Speed
operating.
2. When battery drops
Switch 2
2. After releasing
below 50%: "FREE"
Twice
your right hand,
→"SPORT"→"FREE"
quickly tap on the
* Only in effect for dual
right start button
hand operation mode
twice and then hold it.
1. "LR"→"R"→"L"→"LR".
When the device is
2. The mode is "LR" by
Twice
Hand
switched on while
default after restarting
Operation
not operating, click
the device
Mode
the left start button
3. For APP settings, please
Switch
twice and release it.
refer to SublueGo User
Guide
1.This operation is only
effective in "Left hand
1. Push down the
operation mode". Please set
start buttons with
the left hand operation mode
Left
both hands.
via SublueGo APP or through
Hand
2. Release your right
the device in advance.
Operation
hand when the
2. The user shall understand
device starts
the potential risks of this
operating
mode before adopting this
mode.
1. This operation is only
effective in "Right hand
operation mode". Please
1. Push down the
set the left hand operation
start buttons with
Right
mode via SublueGo APP or
both hands.
Hand
through the device in
2. Release your left
Operation
advance.
hand when the
2. The user shall
device starts
understand the potential
operating
risks of this mode before
adopting this mode
When battery drops below 50%, TURBO speed mode will be banned.
The user shall not use this device unless he or she masters
underwater diving techniques, gets familiar with single hand
opreation in Navbow User Manual, and be in an absolutely safe
water area.
Without any operation, the device will automatically shut down in
20 minutes.
Wearing and Emergency Loosening of the Safety leash
Wearing the Safety leash
Quick Loosening
Single Hand Operation
1
2
3
Install D ring converter
Connect the single
Connect the waist belt
hand lanyard
on the diving suit
4
5
6
Adjust the single lanyard
Operate with both hands
Switch to single hand
to optimal length
until the single hand
operation after
lanyard straightens
stabilization
The user shall not use this device unless he or she masters
underwater diving techniques, gets familiar with single hand
operation in Navbow User Manual, and be inan absolutely safe
water area.
Please operate in FREE mode and get familiar with the device.
When using the device in water, please operate with both hands
first. When the operation stabilizes and the single hand lanyard
straightens, slowly release the other hand and switch to single
hand operation.
4. Display Explanation
Status Indicator
Items
Icon
Rules
Welcome
Page
1. Battery is displayed in 6 blocks
Battery
2. When battery drops below 50%, TURBO
speed mode will be banned
FREE
Low Speed 1m/s
Speed*
SPORT
Middle Speed 1.5m/s
TURBO
High Speed 2m/s
1. Only counted during use
Time of Use
S
2. Time will be cleared after restarting
Unconnected to the mobile APP
Wireless
Connection
Connected successfully to the mobile APP
LR
Dual Hands Operation Mode
Hand
Operation
R
Single Hand Operation Mode - Right Hand
Mode
L
Single Hand Operation Mode - Left Hand
* The speed are test value only and is affected by various factors such
as user, temperature, depth, water current, extensions, user's clothing
and equipment, and so on.
Device Status and Alarm
1. When battery drops below 30%, the device will
Low
send low battery alarm
Battery
2. The battery indicator icon will flash continuously
Alarm
3. The device will give out vibration alarm three
times when the battery drops below 30%
1. When battery drops below 20%, the device will
Extremely
send extremely low battery alarm
Low
2. The battery indicator icon will flash quickly and
Battery
continuously
Alarm
3. The device will give out vibration alarm six times
when the battery drops below 20%
1. The black dot will circle around during self
Self
cleaning
Cleaning
2. Self cleaning will last for 3 minutes
1. No operation can be carried out when safety
lock is switched on. The safety lock icon will flash
Safety
continuously.
Lock
2. Unlock the device via the mobile APP before
operating it again.
When error occurs, the error icon will be displayed
Error
every minute
The arrow will flash continuously and the number
Firmware
Update
indicates updating progress
*
Please check the battery from time to time and return to shore in
time.
*
When error occurs, please stop using this device immediately and
contact SUBLUE or authorized after-sales service center for solution.
