Atlas Copco C8-06 Sicherheitshinweise Seite 3

C8-06
Technical Data
Product Data
Thread Size
C8 Loadcell Size
Max load capacity
Hydraulic pressure area
Stroke
Weight
Maximum working pressure
Declarations
Liability
Many events in the operating environment may affect the
tightening process and shall require a validation of results. In
compliance with applicable standards and/or regulations, we
hereby require you to check the installed torque and rotational
direction after any event that can influence the tightening re-
sult. Examples of such events include but are not limited to:
• age and condition of hydraulic hoses and connections of
the hydraulic pump
• initial installation of the tooling system
• change of part batch, bolt, screw batch, tool, software,
configuration or environment
• change of air- or electrical connections
• change in line ergonomics, process, quality procedures or
practices
• changing of operator
• any other change that influences the result of the tighten-
ing process
The check should:
• Ensure that the joint conditions have not changed due to
events of influence.
• Be done after initial installation, maintenance or repair of
the equipment.
• Occur at least once per shift or at another suitable fre-
quency.
Information regarding Article 33 in REACH
The European Regulation (EU) No. 1907/2006 on Registra-
tion, Evaluation, Authorization and restriction of Chemicals
(REACH) defines among other things requirements related to
communication in the supply chain. The information require-
ment applies also to products containing so called Substances
of Very High Concern (the "Candidate List"). On 27 June
2018 lead metal (CAS nr 7439-92-1) was added to the Candi-
date List.
2.75 8-UN
C8-06
2542.11 kN
255.13 t
16951.84 mm²
26.28 in²
30 mm
1.18 in
kg
lb
1500 bar
21750 psig
© Atlas Copco Industrial Technique AB - 9846 0623 00
In accordance with the above this is to inform you that certain
mechanical components in the product may contain lead
metal. This is in compliance with current substance restriction
legislation and based on legit exemptions in the RoHS Direc-
tive (2011/65/EU). Lead metal will not leak or mutate from
the product during normal use and the concentration of lead
metal in the complete product is well below the applicable
threshold limit. Please consider local requirements on the dis-
posal of lead at product end of life.
Regional Requirements
WARNING
This product can expose you to chemicals including lead,
which is known to the State of California to cause cancer
and birth defects or other reproductive harm. For more
information go to
https://www.p65warnings.ca.gov/
EU DECLARATION OF INCORPORATION
We, Tentec Ltd. C/O Atlas Copco Bolt Tightening Solu-
tions Unit F1, Innovation Drive, Pendeford, Wolverhamp-
ton, England, WV9 5GA, declare under our sole responsibil-
ity that the design of the product (with name, type and serial
number, see front page) is compliant with the following es-
sential requirements of Machinery Directive 2006/42/EC:
2006/42/EC (Annex 1 Clause: 1.1, 1.3, 1.5, 1.6, 1.7)
And that this partly completed machinery is in conformity
with the provisions of the following other EU Directive(s):
2014/68/EU (PED)
This partly completed machinery must not be put into service
until the final machinery into which it is to be incorporated
has been declared in conformity with provisions of the Ma-
chinery Directive 2006/42/EC, where appropriate.
The following (parts/clauses of) European harmonized stan-
dards have been applied:
The relevant technical documentation was compiled and was
communicated in accordance with Machinery Directive
2006/42/EC part B of Annex VII. Authorities can request the
technical file in electronic form from:
Jonathan Gibbs, Quality Manager
Atlas Copco Bolt Tightening Solutions
Unit F1, Innovation Drive, Pendeford
Wolverhampton. England. WV9 5GA
Wolverhampton, 14 August 2024
Nicholas Evans, General Manager
Signature of issuer
Safety Information
3
