Final Installation
1. To complete the installation, simply slide the mount piece with your display attached into the wall
plate.
2. The plastic tab on the top of the wall piece should click,
arm piece is secure.
3. If you need to remove the arm piece, push in on the tab
the mount upwards and then out of the wall plate..
4. For additional security and stability, tighten the security
of the mount piece using the Allen Wrench (H) included in
5. To use the integrated cable management feature,
through the hook located at the bottom of the arms
(see illustration)
Operation and Adjustment
NOTE: Adjustment of your LCD may vary by model.
To adjust the tilt angle or rotate your screen, firmly grasp the
play and carefully move it into position. If you find the mounts is
move or is too loose to hold your mount in position, adjust the
connecgtor.(see illustration)
Swivel adjustments can be made simply by moving your display
position. If the swivel joint is too tight or becomes too loose, it can be adjusted using the S=4 Allen
Wrench(I) provided in your hardware kit (see illustration).
© by WilTec Wildanger Technik GmbH
http://www.wiltec.info
indicating that the
and carefully slide
bolt located on base
the hardware kit.
route the cables
& the wall plate
sides of your dis-
too diffiucult to
knob under the ball
into the desired
