General use
WARNING
Fire hazard! Never use the product for the extraction of
inflammable, glowing or burning particles, substances or
liquids. Never use the product for the extraction and/or
filtration of aggressive vapours (such as hydrochloric acid) or
sharp particles.
•
Inspect the product and check for damage. Verify the operation of the
safety provisions.
•
Check the workspace. Do not allow unauthorised persons into the
workspace.
•
Use your common sense. Stay alert and concentrate on the work. Do
not use the product if you are tired or under the influence of drugs,
alcohol or medication.
•
Always ensure adequate ventilation, especially in smaller areas.
•
Never install the product in front of entrances, exits and passages
intended for emergency services.
•
Ensure that sufficient approved fire extinguishers are available in the
workplace.
•
Protect the product from water and moisture.
•
Do not use the product at a relative humidity above 80%.
•
Do not use the product at temperatures below 5 °C or above 45 °C.
•
Keep the controls free of dirt and grease.
•
The product is not explosion-proof. Therefore, never use the product in
an explosion-hazardous environment, due to possible sparks from the
motor or the filter package.
Service, maintenance and repairs
In this manual, a clear distinction is made between service,
maintenance and repair work that may be carried out by the
user and that which may only be carried out by trained and
authorised service technicians.
•
Switch off the machine for maintenance.
•
Observe the specified maintenance intervals. Overdue maintenance
may result in high repair and overhaul costs and may invalidate
warranty claims.
•
Always use manufacturer-approved tools, parts, materials, lubricants
and service techniques. Never use worn tools and do not leave any
tools in or on the product.
•
Do not carry out any service, maintenance or repair work on the
product until it has been secured against unintentional operation.
•
Safety provisions that have been removed for service, maintenance or
repair purposes must be installed and checked for correct operation
immediately after these operations.
•
Regularly clean the inside of the housing.
•
Replace the filter on time.
4
USED PRODUCTS AND THE ENVIRONMENT
PACKAGING MATERIAL
The packaging used to transport and protect the product
consists mainly of the following recyclable substances:
- solid and corrugated cardboard
- polythene film
- untreated wood
Therefore, do not dispose of the packaging as industrial waste.
Instead, ask your municipal waste management service where
you can submit the material.
Product
Products you dispose of may still contain valuable substances and materials.
Therefore, do not dispose of the product as industrial waste. Instead, ask the
municipality about the possibilities for reuse or environmentally friendly
processing of the material.
5
TECHNICAL DATA
5.1
Technical data DFI 30/60
Max. capacity
Filter surface area
Weight
Filter efficiency
Main filter
Enclosure
6
GENERAL DESCRIPTION
6.1
Dust Free Industrial 30/60 for industrial extraction of dust
and fine particulates
This air cleaner is able to capture the dust and fine particulates released in
many industrial processes, which would normally remain in the room, with a
very high efficiency.
6.1.1
Method of extraction of the polluted air
•
DFI 30/60: through intake grille
6.2
Operation
The polluted air is sucked in and first reaches the filter (fig. 3). All large
particles are captured in this main filter.
Repairs may only be carried out by Euromate or by persons authorised by
Euromate. A maintenance contract is also possible.
7
OPERATION / STATUS
The main switch is used to switch the power on and off.
The LED light on the control box indicates the status of the machine. This is
done using different colours:
Colour code
White
Green
Blue
Red / White
Green / White
With the Air Safety Portal, you control the DFI 30/60. On the Air Safety Portal
there is a user-friendly guide with detailed instructions.
8
DIMENSIONS
8.1
Dimensions DUST FREE INDUSTRIAL 30/60
See figure 2.
9
MAINTENANCE
If the following simple maintenance and cleaning operations are carried out
with due care and at the specified intervals, any problems can often be
detected and corrected before they lead to an interruption of service. The
maintenance intervals may vary from those specified, depending on the
specific working and operating conditions. It is therefore recommended that,
in addition to the periodic maintenance indicated here, the machine be
subjected to a thorough, comprehensive annual inspection. Please contact
your supplier for more information.
User Manual Dust Free Industrial 30/60
DUST FREE INDUSTRIAL 30/60
3000/6000 m
/h
3
4,8 m
2
42/82 kg
Depends on filter class
User's choice
Metal
Description
Standby
On
Initialisation
No connection
Standalone
7
