FS S3410C Serie Schnellstartanleitung Seite 8

LEDs State
RJ45 (for
1~16
S3410C-16TF)
1~16
(Switch Mode)
RJ45 (for
S3410C-16TF-P)
1~8
(PoE Mode)
SFP
SFP1~SFP2
Description
O The port is not linked.
The port is linked up at 10M/100M
Solid Green
/1000M.
The port is sending or receiving
Blinking Green
data at 10M/100M/1000M.
O The port is not linked.
The port is linked up at 10M/100M
Solid Green
/1000M.
The port is sending or receiving
Blinking Green
data at 10M/100M/ 1000M.
O PoE is disabled.
Solid Green PoE is enabled.
Blinking Green PoE is overloaded.
O The port is not linked.
Solid Green
The port is linked up at 1G.
The port is sending or receiving
Blinking Green
data at 1G.
An error occurs when the
Solid Red
transceiver sends signals.
An error occurs when the
Solid Yellow
transceiver receives signals.
7
