3. Dismantle the middle hinge, the screws, the screws hole caps and remove the
freezer door.
4. Dismantle the bottom hinge, hole caps and screws, Install the bottom hinge
shaft on other side of the bottom hinge, then install the hinge on the other
side.
screw
screw cap
5. Dismantle the screws, sleeve pipe and stopper on the lower end cover of the
two door bodies, and install them successively on the other side of the door
bodies (the stopper needs to be replaced from the additional bag). Then
remove the upper end cover of the cooler door and switch the wire harness
with a sleeve pipe to the other side of the door body. Finally install the sleeve
pipe of the upper hinge on the cooler door in the hole on the other side of
upper end cover of the cooler door.
hole cap
07
shaft
shaft
EN
