Step 3: Lift the cover of head support and pull the shoulder belts at front to remove them.
To protect your child! The extra pad provides your child with the support they need while he or she is even smaller.The extra
padding is used to provide extra comfort for very small babies. Attention! Please use the extra pad attached to this car seat model
until your child reaches a height of 60 cm (approx. 3 months). The newborn inlay may be removed after the baby is 75 cm to
provide more space for the child. To remove the newborn inlay open and remove the shoulder pads. Then remove the newborn
inlay and place the shoulder pads back on the shoulder belts.
Press the roation button to rotate the child seat to 180° или 360°. The seat is rotatable in both directions. By fixing in
required position (car seat FORWARD facing or REARWARD facing) you will hear a click sound. For reference see figure H:
•
Figure A: shows the Forward installation method.
•
Figure B: after rotating the seat to 180° it will be into Backward installation method.
•
Figure C: after rotating the seat respectively to 90° and 270° it will be in the baby holding position.Attention! The
function is only active when the vehicle is not in movement.
Pull the lever for recline and set the seat un required position as follows (see Figure I for reference):
•
Rearfacing seat: Five possible recline positions for the seat as shown in Figure I.3.
•
Forward-facing seat: Five possible recline positions as shown in Figure I.2.
CHILD SEAT INSTALLATION IN REARWARD FACING POSITION - FIGURE J
Installation with ISOFIX and support leg (rearward facing).
Use the chair's 5-point safety harness to ensure your child's safety.
1. Place the car seat on vehicle seat, install ISOFIX attachment, fix the support leg to the floor.
2.Place the child in car seat, put and lock the 5-point safety harness.
3. Press the lever and rotate the seat, so that it faces the backrest of vehicle seat (child is rearward facing).
Installation with ISOFIX and support leg (forward facing).
Use the chair's 5-point safety harness to ensure your child's safety.
1. Place the car seat on vehicle seat, install ISOFIX attachment, fix the support leg to the floor.
2.Place the child in car seat, put and lock the 5-point safety harness.
3. Press the lever and rotate the seat, so that it faces the direction of vehicle traffic (child is forward facing).
CHILD SEAT INSTALLATION IN FORWARD FACING POSITION - FIGURE L
Installation with ISOFIX and 3-point safety belt (forward facing) – figure L.1.
1.Store the support leg under the base.
2.Install ISOFIX attachments to ISOFIX slots at vehicle.
3.Place the child in the car seat and set the height of head support based on the child's height.
4.Pull the 3-point safety belt of vehicle.
5.Thread the diagonal belt though the guide of head support, and the lap through the guide of base and lock them
into the vehicle buckle.
Installation with 3-point safety belt (forward facing) – figure L.2.
1.Store the support leg under the base.
2.Place the child in the car seat and set the height of head support based on the child's height.
THE NEWBORN INLAY - FIGURE G
360 ° SEAT ROTATION- FIGURE H
BACKREST RECLINING- FIGURE I
CHILD'S HEIGHT: 40-105 cm
Using: ISOFIX + Support leg + 5-point safety harness
CHILD SEAT INSTALLATION IN FORWARD FACING POSITION - FIGURE K
CHILD'S HEIGHT: 76-105 cm
Using: ISOFIX + Support leg + 5-point safety harness
CHILD'S HEIGHT: 100-150 cm
Using: ISOFIX + 3-point safety belt of the car
Using: ISOFIX + 3-point safety belt
- FIGURE B.3
- FIGURE B.1
- FIGURE B.1
- FIGURE B.1
