Safety notes

Operating voltage 230 VAC!
Risk of injury from electric shock!
Connection has to be carried out only by an
authorized electrical specialist!
- Lay and insert weak current conductions
separately from supply mains
- Only for inside mounting
- Just use unchanged original D+H parts

Guarantee

You will get 2 years guarantee for all D+H products
from date of verified handing over of the system up to
maximal 3 years after date of delivery, when
mounting and starting has been carried out by an
authorized D+H-distributor.
D+H guarantee is expired, with connection of D+H
components with external systems or with mixing of
D+H products with parts of other manufacturers.

Declaration of Conformity

We declare under our sole responsibility that the
product described under "Technical Data" is in
conformity with the following directives:
2004/108/EC, 2006/95/EC
Technical file at:
D+H Mechatronic AG, D-22949 Ammersbek
Thomas Kern Maik Schmees
Member of the Board Authorized signatory, Technical Director
28.10.2013
99.820.19 3.0/10/13

Intended use

- Ventilation control for small sized building objects
- For triggering of 230 V AC ventilation drives
- Connection of up to 8 D+H drives
- 1 ventilation group
- Possibility of connecting up to 20 groups via
cutoff relays TRL 8 at 24 V DC output
- Weather monitoring (central CLOSE) in
conjunction with several TRL 8
- Only for inside mounting

Performance features

- LED-displays for wind and rain, exceeding of wind
threshold value and automatic operated ON/OFF
- WRZ 8000 in addition with luminous band for wind
force (Beaufort) and LED for wind signal memory
function (Signal is stored to avoid continously
running of the drives with gusts of wind.)
- In case of WRZ: adjustable switching point of wind
force (4 or 6 Bft.) at wind/ rain transmitter WRG 82,
signal retention time: 10 minutes
- In case of WRZ 8000: infinitely adjusting of
switching point of wind force (2 to 8 Bft.) and signal
retention time (1 to 15 minutes ) at control panel
- Only buttons with mutual interlocked NOC's must
be used with vent buttons by customer

Maintenance and cleaning

Inspection and maintenance has to be carried out
according to D+H maintenance notes. Only original
D+H spare parts may be used. Repair is to be carried
out exclusively by D+H.
Wipe away debris or contamination with a dry, soft
cloth.
Do not use cleaning agents or solvents.

Disposal

Electrical devices, accessories, batteries and packa-
ging should be sorted for environmental-friendly
recycling.
Do not dispose electrical devices and batteries into
household waste!
Only for EC countries:
According the European Guideline 2002/96/EC for
waste electrical and electronic equipment and its
implementation into national right, electrcal devices
that are no longer usable must be collected separa-
tely and disposed of in an environmentally correct
manner.
