Figure 3: the display
AC DC
Measurement of the AC DC signal
AC + DC
Measurement of the AC and DC signal
AUTO
Auto-ranging
∆ REL Relative values compared with a reference
∆ MEM Presence of a relative value in memory
HOLD
Memorisation and display of memorised values
MAX MIN
Maximum Minimum RMS value
PEAK+ PEAK- Maximum peak value
.run r.un ru.n Capacitance meter, acquisition in progress
-----
Frequency measurement impossible
O.L. Measurement capacities exceeded
V Hz F A Volt
°C °F Degrees Celsius - Degrees Fahrenheit
% Ω
Percentage Ohm
N µ m k M Symbol of the nano- micro- milli- kilo- mega-prefix
Audible continuity measurement symbol
Measurement and testing of semiconductor junctions
Permanent mode
Low-battery indictor
1
Figure 4: the terminals
THE DISPLAY
Hertz
THE TERMINALS
2 3 4
Farad Ampere
Item Terminals
1
6 A, 10 A current
2
20 µA, 6 000 µA,
60 mA, 600 mA current
3
Common
4
Other measurements
