Example setup

The Mixmaster can be used with most types of engines and oscilloscopes, so no two
setups will be the same. To get you started, we describe a typical setup that you
can modify to suit your application.
Engine under test
Bank B cables
Bank A cables
Mixmaster
6
Ground lead
Pico Technology Limited
PC or laptop
running
PicoScope
software
Pico
PC Oscilloscope
Trigger cable
Channel A cable
Channel B cable
