2. IN GENERAL
The TEEPRES is a device that enables pumps, with a minimum prevalence of 2 bar, to start and stop
®
automatically, with regard to a drop in pressure (opening of the taps) and to the stopping of the flow
through the system (closing of the taps) respectively.
Should the water supply be interrupted for any reason, TEEPRES
stopping the pump, thus protecting it from harmful dry running.
l The TEEPRES is to be used exclusively for non abrasive clear water without debris and other
®
dirt. In the opposite case, an effective pre-filter with a mesh size should be installed no coar-
ser than 0.2 mm in front of the device.
l It is not recommended to install the unit in wells or in dense enclosures, as strong condensation may
occur. If there is a risk of ice forming due to low ambient temperatures, it is recommended to protect
TEEPRES and the pump accordingly.
®
Make sure after unpacking that the data given on the nameplate agree with the foreseen opera-
ting conditions. When in doubt, the operation is prohibited.
Transport damages are reported immediately to the transport company and to us in writing.
3. OPERATING CONDITIONS
A. Compatible / non compatible fluids
TEEPRES is suitable for use with clean
®
water and chemically non-aggressive
liquids. If the fluid contains impurities, a
filter should be fitted upstream.
B. Environmental conditions
TEEPRES should not be used where
®
there is the risk of an explosion. The
temperature of the location should range
between 0°C and 65°C, and the humidity
should not exceed 90%.
C. Power supply
Make sure that the variation in the power
supply is never more or less than 10 %
of the RATING value. Higher values may
cause damage to the electronic compo-
can only be used with
nents.TEEPRES
®
single-phase pumps.
4. INSTALLATION
The pump should be installed and serviced by qualified personnel, responsible for ma-
king the hydraulic and electrical connections in compliance with the relevant regulations.
1A PROFI HANDELS GMBH shall not be held liable for any damage relating to, or resulting
from, an improper use of the product, or for any damage relating to, or resulting from, servicing
or repairs carried out by unqualified personnel and/or with non-OEM spare parts. The warranty,
which is valid for 24 months from the date of purchase, will no longer be applicable should the
product suffer damage as a consequence of the use of non- OEM spare parts, tampering or
improper use.
When starting the installation, check the following:
l the power supply is switched off
l the power lines can withstand the maximum current
l the cable bushings and circuit board cover have been properly assembled and secured (see
Electrical Connections).
English 3
performs the important function of
®
