Dispose of the used oil in accordance with appli-
cable regulations.
m Warning!
Never run the engine without the air filter ele-
ment installed.
Lubricate angle transmission
Lubricate with lithium-based grease. Remove the
screw and put in the grease, turning the shaft manu-
ally until grease emerges, then replace the screw.
Storing the unit
After cutting, clean the unit thoroughly. Store the unit
in a dry room allow the motor to cool down before-
hand.
Important hint in case of sending the equipment
to a service station:
Due to security reasons please see to it that the
equipment is sent back free of oil and gas!
Service information
Please note that the following parts of this product
are subject to normal or natural wear and that the fol-
lowing parts are therefore also required for use as
consumables.
Wear parts*: Line spool, cutting blade, spark plug, air
filter
* Not necessarily included in the scope of delivery!
Spare parts and accessories can be obtained from
our service centre. To do this, scan the QR code on
the cover page.
11. Storage
Cleaning
• Keep handles free of oil, so you always have a se-
cure hold.
• Clean the equipment as required with a damp cloth
and, if necessary, mild washing up liquid.
m Important!
• Always pull out the spark boot plug each time be-
fore carrying out any cleaning.
• Never immerse the equipment in water or other liq-
uids in order to clean it.
• Store the chainsaw in a safe and dry place out of
the reach of children.
Storage
Important: Never put the equipment into storage for
longer than 30 days without carrying out the follow-
ing steps.
Storing the equipment
If you intend to store the equipment for longer than
30 days, the equipment must be prepared accord-
ingly. Otherwise the fuel still remaining in the carbu-
retor will evaporate and leave a rubbery sediment.
This can cause problems when starting up the equip-
ment and may require expensive repairs.
1 Slowly remove the fuel tank cap to release any
pressure that may have formed in the tank. Care-
fully empty the tank.
2 To remove the fuel from the carburetor, start the
engine and let it run until the equipment stops.
3 Leave the engine to cool (approx. 5 minutes).
4 Remove the spark plug (see section 10 Change
and clean the spark plug).
5 Add one teaspoon of 4-stroke engine oil into the
combustion chamber. Slowly pull the starter cord
several times to apply a layer of oil to all internal
components. Fit the spark plug again.
Note: Store the equipment in a dry place and far
away from possible ignition sources such as an oven,
a gasfired hot water boiler, a gasfired dryer, etc.
Putting the equipment back into operation
1 Remove the spark plug (see section 10 Change
and clean the spark plug).
2 Quickly tug on the starter cord to remove excess
oil from the combustion chamber.
3 Clean the spark plug and check that the electrode
gap is correct, or insert a new spark plug with the
correct electrode gap.
4 Prepare the equipment for operation.
5 Fill the tank with proper fuel locations.
6 Check it the oil level.
Transport
To transport the machine, empty the petrol tank as
described in section 8 draining fuel. Clean coarse dirt
off the equipment with a brush or hand brush.
12. Disposal and recycling
Notes for packaging
You can find out how to dispose of the disused
device from your local authority or city adminis-
tration.
www.scheppach.com
The packaging materials are
recyclable. Please dispose of
packaging in an environmen-
tally friendly manner.
GB | 31
