2. Removal and attachment of the tail light
• Release the LED back light from below with the help of a coin or similar (Fig. J).
• To remove the rear light, pull the rear light out of the holder (Fig. J).
• To attach it, the LED rear light must be re-plugged on the holder provided for this purpose.
3. Functions
The LED rear light has three different functions, each of which can be used as desired
(Fig.K).
• Press x1: continuous light,
• press x2: flashing light,
• press x3: colour chaser,
• press x4: light off.
4. Changing the batteries
The LED tail light comes equipped with a CR 1620 (3V) battery.
• To replace the battery, unlock the screws at the back of the light using a small Phillips type
head screwdriver.
• Subsequently, lift off the lid and the circuit board, exchange the battery and remount the
circuit board and the lid. In doing so, please make sure that the polarity is correct when
installing the new battery (Fig. L). The + pole points downwards when the batteries are
inserted.
• Now, attach the lid again using the four screws (Fig. L).
• Battery type: 1x CR1620, 3V 0,2W
5. Cleaning and care
The housing of the LED rear light can be cleaned with a damp cloth.
6. Disposal
Please do not dispose of flat batteries via the household waste, but instead use the collecting
container intended for this purpose.
Old devices must not be disposed of with household waste!
If the product can no longer be used, every user is required by law to dispose of
the device separately from household waste, e.g. at a collection point in their com-
munity/borough. This ensures that old devices are recycled properly and also avoids
pollution of the environment. For this reason, electrical equipment is marked with the
symbol shown here.
