Installation Instructions for the Plumber:
Important: These instructions should be read carefully before
fitting is begun. The exact location in the salon should be
determined in consultation with the owner and the shop-fitting
specialist.
Caution:
•
The shampoo station is intended for operation in clean
and dry rooms at normal room temperature.
•
In the water supply system only original components
supplied by the manufacturer must be used.
•
The house installation must be equipped with a pressure
reducing valve. Recommended water pressure for the
shampoo station: approx. 3 – 5 bar.
•
The new set of hoses supplied with the unit must be
used. Old hoses must not be used.
•
Ensure that the height of the drain and installation
tunnel is correct.
1.
We recommend to provide the supply lines with a
central shut-off device, which must be easily accessible
from the salon.
If the system is operated without a suitable shut-off
device, the angle valves must be closed at the end of
business hours.
2.
The supply pipes and waste pipes must be laid in
accordance with Fig. 4.
Hot- and cold water pipes R 1/2"
drain 400 mm above finished floor
In the case of in-line installation at floor installation use
the installation template!
Installation Instructions for the Shop-Fitter:
3.
Put the shampoo unit in the correct position. (with in-line
installation: centre - centre of unit: 65 cm, with chair top
Loop S 75 cm).
4.
Dismantle the casing (Fig. 1)
Section 7/2:
remove the three M5 screws on each
side as well as one screw at the
bottom.
Take out section 7/2 to the rear.
Section 7/1 + 7/3: remove 3 screws and take out
sidewards.
5.
After lining up the pedestal, drill the floor-holes
corresponding to the installation template and fix pedestal
to the floor!
6.
Fix the wash basin with the rubber underliner to the
pedestal. Push the drain hose through the drilling in the
stress-bearing construction, lead the pressure tubes and
the hand shower hose incl. protecting hose beside the
stress-bearing construction.
7.
Fix the pressure hoses and waste-water hose to the
pedestal by means of the 2 cable clips.
Important: Make sure there is a sufficient gap (approx.
10 – 15 mm) between the plate for the tilting device and
the pressure hoses, to prevent abrasion!
8.
Prepare connection of installation tunnel (3):
Connection to shampoo station: (Fig. 3)
Observe the assembly side according to the installation
plan!
Make 1 drilling Ø 80 mm and 4 drillings Ø 5,5 mm.
Mount the connection adapter (2) with connection
rubber (1) using M5 screws, washers and nuts
Connection to wall: (Fig. 4)
Fix 3 mounting brackets (4) to the wall
LavaSit Joy MO – W+R
GB
Installation Instructions for the Plumber:
9.
Make sure the copper pipes/pressure hoses and waste-
water hoses are parallel.
Screw the waste pipe 40 mm (42.8 mm in Australia) and the
pressure pipes R ½" to the stop-cocks between wall and unit.
Secure stop valves against rotating when bolting!
The waste-water hose and S-bend are connected by means of
sleeve nut and seal. The waste-water hose must be inserted at
least 3 - 4 cm into the S-bend!
Connect the drain and waste water hose by means of a hose
clamp.
10.
Close the mixer tap. Open the stop-cock and check for tightness
with the mixer tap closed.
Check the mixed water.
The hot and cold water supplies must correspond with the
coloured symbols on the mixer tap.
11.
Pressure-test the unit with maximum water pressure, then set
water pressure to 3 - 5 bar. After completion of installation
work, the water pipes must be flushed through.
Where there are several units, a main stop-cock is necessary,
which must be easily accessible from the salon.
These installation instructions apply to a single unit. Where
there are several units, the cross section of the piping must be
correspondingly larger.
Important: Where the water pressure exceeds 5 bar, it must be
regulated by means of a pressure reduction valve. Since a pressure
reduction valve is required for a hot water boiler, it can be fitted at the
same time with the general water supply.
To the owner:
Up To this point, the plumber must install the unit and assume
warranty. The plumber is responsible for any defects occurring here.
The manufacturer of the unit accepts no liability for this work!
Installation Instructions for the Shop-Fitter:
12. Only remove the protective foil from the casing elements
immediately before fitting them.
Important: check that all jointing strips are available, to avoid
scratching the elements when fitting!
Refit the casing parts (Fig. 1)
Section 7/1 + 7/3: push onto section 8 and fix by means of M5
Section 7/2:
13. Attach installation tunnel: (Fig. 3)
Shorten installation tunnel if necessary and provide it with edge
protection rubber at wall side.
Put on installation tunnel.
Put on connecting brackets (5) to under side of installation tunnel.
14. Fit the chair (Fig. 2)
Different depths of chairs as well as backrest tilt need different
installation positions to reach an ergonomically seat position.
LavaSit Joy (fixed backrest):
Bow, Flow, Mellow, Shape, Vogue: ..................... install. position 1
Cove: ........................................................................... install. position 2
Attach chair top (9.1) together with seat receiver (9) onto seat
support (8.1) by means of 4 screws.
LavaSit Joy synchron (tilting backrest):
Cosmo S, Cube R, Kite S: ...................................... install. position 1
Loop S, Pillow S, 8020 S: ........................................ install. position 2
Arrow S, 4020 S: ...................................................... install. position 3
Put the chair top onto the pre-mounted spacer pieces of the
seat support and fasten from down by means of 4 nuts M8.
Important: With LavaSit Joy synchron make sure that there is
no contact between the swivel heads and the cover during linear
movement of the seat.
Line up the chair in the unit and fix into position.
Connect the unit.
screws.
push onto section 7/1 + 7/3 and fix by means
7 screws.
751 210 03-2021
