3. Install the main unit on the indoor surface wall, and connect the adapter wire from the back
of the main unit to the wiring of the fan and temperature sensor exposed by the inner duct
in the wall. Tidy the wiring, align the main unit with the plastic block protruding on the back
cover board and install it in. (There are corresponding concave holes on the back of the main
unit.) Just install it, no other operations are required. The back of the main unit is equipped
with a strong magnet, which will automatically attract the mounting plate on the wall (After
installation, please check that if there is a large gap between the main unit and the mounting
plate. If yes, it means that the wires in the main unit are not sorted out. Therefore, please
remove the main unit and reinstall it)
to dry.
Then install the back cover mounting plate,
align the round hole of the back cover
the mounting plate with the round hole
on the wall, and measure the level of the
mounting plate with a level ruler to ensure
that the mounting plate installation is
horizontal, then mark the hole, punch in
the expansion rubber grain, then align the
mounting plat
with a screw.
3. If there are no occasions in the installation
of the environment where rainwater can
be directly spilled to the ERV, you can
insert the accessory silicone seal from the
accessory bag into the outer air duct, and
then install the duct into the wall. It can be
sealed with the wall and the duct plays the
CONNECTION TO POWER
role of waterpr
possible to proceed without carrying out
CONNECTION TO POWER
steps 2 and there is no need to use PU glue
DISCONNECT THE VENTILATION FROM THE POWER SUPPLY TO ANY
ELECTRIC INSTALLATION OPERATIONS.
THE VENTILATOR IS DESIGNED FOR CONNECTION TO SINGLE-PHASE
AC 100-240V/50-60 HZ POWER SUPPLY. CONNECT THE VENTILATOR
TO THE SOCKET DIRECTLY.
depth.)
1
1
3
3
g. In this case, it will be
for the user and the installer
3
Plug the inner air duct into
the hole and make the wire
inside the inner air duct face
2
down, which direction should
be the
same
2
as the
mark of
the outer
duct.
4
4
Silicone sealing ring
4
89
should be
on top of the
round hole when installing the
back cover mounting plate.
5
Outer duct
Disconnect The Ventilation
From Power Mains To
Any Electric Installation
Operations.
