VENTILATOR INSTALLATION
1. Prepare a round hole through the inner
wall. The hole size is shown below
hole size is shown below.
2. Insert the PVC pipe into the wall, adjust the fit
with the wall, and then fill the gap between the
PVC pipe and the wall with PU foam inside and
outside. Then open the hood cover and align the
bottom of the hood base with the circle. Punch
holes on the exhaust hood, and secure the bottom
of the plastic hood with expanding glue pellets
and screws.
PVC pipe
Outdoor
Exhaust
hood
base
The grille on the lower cover of the
plastic outer hood is facing please
pay attention tomark the screw
holes when installing
Indoor Outdoor
for the user and the installer
