IMPORTANT REMARKS

V2 has the right to modify the product without previous
notice; it also declines any responsibility to damage or
injury to people or things caused by improper use or wrong
installation.
• This instruction manual is only for qualified technicians, who
specialize in installations and automations.
• The contents of this instruction manual do not concern the end
user.
• Every programming and/or every maintenance service should
be done only by qualified technicians.
• The installer must provide for a device (es. magnetotermical
switch) ensuring the omnipolar sectioning of the equipment
from the power supply. The standards require a separation of
the contacts of at least 3 mm in each pole (EN 60335-1).
• After making connections on the terminal board, use one
hose clamp to fix dangerous voltage wires near the terminal
board and another hose clamp to fix safety low voltage wires
used for accessories connection; this way, in case of accidental
detachment of a conducting wire, dangerous voltage parts will
not come into contact with safety low voltage ones.
• The plastic case has an IP55 insulation; to connect flexible or
rigid pipes, use pipefittings having the same insulation level.
• Also the automation upstream electric system shall comply with
the laws and rules in force and be carried out workmanlike.
The MISTRAL sensor detects the wind speed and transmits
this parameter to the connected controller by cable.
To install MISTRAL, carefully read these instructions.

TECHNICAL DATA

Maximum applicable voltage: 230 V ~ 50Hz (to GND)
Absorbed power: 3,5 W
Protection: IP44
Temperature for use: -20 ÷ +60 °C
INSTALLATION
CAUTION: For correct operation, please remember that the
sensor must be positioned near the sunshade it protects and in an
area exposed to sun and wind.
The articulated arm should be parallel to the ground and
the blades should be turned downwards (Fig. 3).
1. Remove the cover (Fig. 1)
2. Attach the device to the wall using the provided wall plugs
(Fig. 1)
3. Position the articulated arm horizontally with the blades turned
downwards (Fig. 3)
CAUTION: If the articulated arm is not perfectly horizontal there
may be problems detecting the wind speed.
4. Tighten the screw, V1 (Fig. 3), to lock the movement of the
arm
- 6 - ENGLISH
ELECTRICAL WIRING
1. Connect the anemometer terminal L to the control unit phase
(section 1 mm - 300/500V).
2
2. Connect the OUT terminal of the anemometer to the sensor
input of the control unit (section 1 mm
CAUTION: The sensor can control a maximum of 4 devices.
3. Block the cable using the provided cable gland
4. Close the cover
2 - DISPOSAL
As for the installation operations, even at the end of this product's
life span, the dismantling operations must be carried out by
qualified experts.
This product is made up of various types of materials: some can
be recycled while others need to be disposed of.
Find out about the recycling or disposal systems envisaged by your
local regulations for this product category.
Important! – Parts of the product could contain pollutants or
hazardous substances which, if released into the environment,
could cause harmful effects to the environment itself as well as to
human health.
As indicated by the symbol opposite, throwing away this product
as domestic waste is strictly forbidden. So dispose of it as
differentiated waste, in accordance with your local regulations,
or return the product to the retailer when you purchase a new
equivalent product.
Important! – the local applicable regulations may envisage heavy
sanctions in the event of illegal disposal of this product.

EU DECLARATION OF CONFORMITY

The manufacturer V2 S.p.A., headquarters in Corso Principi di
Piemonte 65, 12035, Racconigi (CN), Italy
declares that the products: MISTRAL
comply with the essential requirements established by the
following directives:
• 2014/30/UE (EMC Directive)
• 2014/35/UE (Low Voltage Directive)
• RoHS-3 2015/863/EU
Racconigi, 01/03/2023
The legal representative of V2 SPA
Roberto Rossi
2 - 300/500V).
