.(262 ‫ﺍﺷﺣﻥ ﻣﺟﻣﻭﻋﺔ ﺍﻟﺑﻁﺎﺭﻳﺔ ﻗﺑﻝ ﺃﻭﻝ ﺍﺳﺗﺧﺩﺍﻡ ﺣﺗﻰ ﺗ ُ ﺷ ﺣ َ ﻥ ﺑﺎﻟﻛﺎﻣﻝ )ﺍﻧﻅﺭ ﺍﻟﻔﺻﻝ ﺷﺣﻥ ﻣﺟﻣﻭﻋﺔ ﺍﻟﺑﻁﺎﺭﻳﺔ ﺑﺎﻟﺻﻔﺣﺔ‬
.‫ﻳﻧﺑﻐﻲ ﺗﻭﻓﻳﺭ ﺍﻟﺗﻬﻭﻳﺔ ﺍﻟﻛﺎﻓﻳﺔ ﻭﺍﻟﺗﺄﻛﺩ ﻣﻥ ﺗﺑﺩﻳﺩ ﺍﻟﺣﺭﺍﺭﺓ ﺍﻟﻣﺗﻭﻟﺩﺓ ﻓﻲ ﺃﺛﻧﺎء ﻋﻣﻠﻳﺔ ﺍﻟﺷﺣﻥ ﻣﻥ ﻣﺟﻣﻭﻋﺔ ﺍﻟﺑﻁﺎﺭﻳﺔ‬
‫ﻳﻌﺗﻣﺩ ﻭﻗﺕ ﺍﻟﺷﺣﻥ ﺍﻟﻣﻁﻠﻭﺏ ﻟﻣﺟﻣﻭﻋﺔ ﺍﻟﺑﻁﺎﺭﻳﺔ ﻋﻠﻰ ﻣﺻﺩﺭ ﺍﻟﺷﺣﻥ ﺍﻟﻣﺣﺩﺩ ﻭﻣﺩﺧﻝ ﺍﻟﺷﺣﻥ. ﻳﻣﻛﻥ ﺷﺣﻥ ﻣﺟﻣﻭﻋﺔ ﺍﻟﺑﻁﺎﺭﻳﺔ ﺍﻟﻣﺣﻣﻭﻟﺔ ﺣﺗﻰ 06 ﻭﺍﺕ ﻋﺑﺭ‬
‫ ﻭﻣﺩﺧﻝ ﺍﻟﺗﻳﺎﺭ ﺍﻟﻣﺳﺗﻣﺭ ﻓﻲ ﻭﻗﺕ ﻭﺍﺣﺩ، ﺗﻣﻛﻥ ﺯﻳﺎﺩﺓ‬USB­C ‫ ﺃﻭ ﺣﺗﻰ 001 ﻭﺍﺕ ﻋﺑﺭ ﻣﺩﺧﻝ ﺍﻟﺗﻳﺎﺭ ﺍﻟﻣﺳﺗﻣﺭ. ﻋﻧﺩ ﺍﻟﺷﺣﻥ ﻋﺑﺭ ﻣﺩﺧﻝ‬USB­C ‫ﻣﺩﺧﻝ‬
.‫ ﺑﻣﺟﻣﻭﻋﺔ ﺍﻟﺑﻁﺎﺭﻳﺔ‬USB­C ‫ﻭﺻﻝ ﻣﺻﺩﺭ ﻁﺎﻗﺔ ﻣﻧﺎﺳﺏ )ﻋﻠﻰ ﺳﺑﻳﻝ ﺍﻟﻣﺛﺎﻝ، ﺑﻁﺎﺭﻳﺔ ﺳﻳﺎﺭﺓ، ﻟﻭﺡ ﻁﺎﻗﺔ ﺷﻣﺳﻳﺔ( ﺑﻣﺩﺧﻝ ﺍﻟﺗﻳﺎﺭ ﺍﻟﻣﺳﺗﻣﺭ ﺃﻭ ﻣﺩﺧﻝ‬
‫ ﺍﻟﺧﺎﺹ ﺑﻣﺳﺗﻭﻯ ﺍﻟﺷﺣﻥ‬LED ‫ﻳ ُ ﻅﻬﺭ ﻣﺅﺷﺭ ﺣﺎﻟﺔ ﺍﻟﺑﻁﺎﺭﻳﺔ ﺣﺎﻟﺔ ﺍﻟﺷﺣﻥ )ﺍﻧﻅﺭ ﺍﻟﻔﺻﻝ ﺍﻟﺗﺣﻘﻖ ﻣﻥ ﺣﺎﻟﺔ ﺍﻟﺷﺣﻥ ﺑﺎﻟﺻﻔﺣﺔ 262(. ﻳﻭﻣﺽ ﻣﺅﺷﺭ‬
.‫ ﺍﻟﺧﺎﺻﺔ ﺑﻣﺅﺷﺭ ﺣﺎﻟﺔ ﺍﻟﺑﻁﺎﺭﻳﺔ‬LED ‫ﺗﺗﻭﻗﻑ ﻋﻣﻠﻳﺔ ﺍﻟﺷﺣﻥ ﺗﻠﻘﺎﺋ ﻳ ً ﺎ ﻋﻧﺩ ﺷﺣﻥ ﻣﺟﻣﻭﻋﺔ ﺍﻟﺑﻁﺎﺭﻳﺔ ﺑﺎﻟﻛﺎﻣﻝ. ﺗﺿﻲء ﻛﻝ ﺃﺿﻭﺍء‬
.‫ ﻓﻲ ﺍﻟﻭﻣﻳﺽ ﻟﺑﻳﺎﻥ ﺣﺎﻟﺔ ﺍﻧﺧﻔﺎﺽ ﺷﺣﻥ ﺍﻟﺑﻁﺎﺭﻳﺔ‬LED 1 ‫ﺑﻣﺟﺭﺩ ﺃﻥ ﺗﻧﺧﻔﺽ ﺣﺎﻟﺔ ﺍﻟﺷﺣﻥ ﺇﻟﻰ ﺃﻗﻝ ﻣﻥ 5 ٪، ﻳﺑﺩﺃ ﺍﻟﻣﺅﺷﺭ‬
‫ﺳﻌﺔ ﺍﻟﺑﻁﺎﺭﻳﺔ‬
٪ 0
٪ 20 ... 5
٪ 40 ... 21
٪ 60 ... 41
٪ 80 ... 61
٪ 100 ... 81
262
.‫ﺗﺄﻛﺩ ﻣﻥ ﺃﻥ ﺟﻬﺩ ﺍﻟﺩﺍﺋﺭﺓ ﺍﻟﻣﻔﺗﻭﺣﺔ ﻟﺑﻁﺎﺭﻳﺔ ﺍﻟﺳﻳﺎﺭﺓ ﺃﻭ ﺍﻟﻭﺣﺩﺓ ﺍﻟﺷﻣﺳﻳﺔ ﻻ ﻳﺗﺟﺎﻭﺯ 23 ﻓﻭﻟﺕ‬
.‫ﻳﺩﻋﻡ ﻣﺩﺧﻝ ﺍﻟﺗﻳﺎﺭ ﺍﻟﻣﺳﺗﻣﺭ ﻛﻼ ً ﻣﻥ ﺍﻟﺷﺣﻥ ﻋﺑﺭ ﺑﻁﺎﺭﻳﺎﺕ ﺍﻟﺳﻳﺎﺭﺍﺕ ﻭﺍﻟﺷﺣﻥ ﻋﺑﺭ ﺍﻟﻁﺎﻗﺔ ﺍﻟﺷﻣﺳﻳﺔ‬
.(261 ‫ ﺑﺎﻟﺻﻔﺣﺔ‬ ‫ﺍﺿﻐﻁ ﻋﻠﻰ ﺍﻟﺯﺭ ﻟﺗﻧﺷﻳﻁ ﺃﻭ ﺇﻟﻐﺎء ﺗﻧﺷﻳﻁ ﻣﺅﺷﺭ ﺣﺎﻟﺔ ﺍﻟﺑﻁﺎﺭﻳﺔ )8، ﺷﻛﻝ‬
.‫ﻳﺗﻭﻗﻑ ﻣﺅﺷﺭ ﺣﺎﻟﺔ ﺍﻟﺑﻁﺎﺭﻳﺔ ﺗﻠﻘﺎﺋ ﻳ ً ﺎ ﺇﺫﺍ ﻟﻡ ﻳﺗﻡ ﺗﻭﺻﻳﻝ ﺃﻱ ﺣﻣﻝ ﺃﻭ ﻣﺻﺩﺭ ﺷﺣﻥ‬
.(‫ﻳ ُ ﻅﻬﺭ ﻣﺅﺷﺭ ﺣﺎﻟﺔ ﺍﻟﺑﻁﺎﺭﻳﺔ ﺣﺎﻟﺔ ﺍﻟﺷﺣﻥ ﺑﻳﻥ 0 ٪ )ﺍﻟﺗﻔﺭﻳﻎ( ﻭ001 ٪ )ﺍﻟﺷﺣﻥ ﺍﻟﻛﺎﻣﻝ‬
LED 5 LED 4
.‫ﺿﻊ ﻣﺟﻣﻭﻋﺔ ﺍﻟﺑﻁﺎﺭﻳﺔ ﻋﻠﻰ ﻗﺎﻋﺩﺓ ﺛﺎﺑﺗﺔ ﻭﻣﻘﺎﻭﻣﺔ ﻟﻠﺣﺭﺍﺭﺓ‬
.‫ﺍﻓﺗﺢ ﻏﻁﺎء ﺍﻷﺟﻬﺯﺓ ﻟﻠﻭﺻﻭﻝ ﺇﻟﻰ ﺍﻟﺗﻭﺻﻳﻼﺕ ﻭﻋﻧﺎﺻﺭ ﺍﻟﺗﺣﻛﻡ‬
.‫ﺍﻷﻋﻠﻰ ﺍﻟﺗﺎﻟﻲ ﺣﺗﻰ ﻳﺗﻡ ﺍﻟﻭﺻﻭﻝ ﺇﻟﻰ ﻣﺳﺗﻭﻯ ﺍﻟﺷﺣﻥ ﺍﻟﻛﺎﻣﻝ‬
.‫ﺑﻌﺩ ﺍﻟﺷﺣﻥ، ﺍﻓﺻﻝ ﻛﻝ ﻛﺎﺑﻼﺕ ﺍﻟﺷﺣﻥ ﻭﺃﻏﻠﻖ ﻏﻁﺎء ﺍﻷﺟﻬﺯﺓ‬
‫ﻣﺅﺷﺭ ﺣﺎﻟﺔ ﺍﻟﺑﻁﺎﺭﻳﺔ‬
LED 3 LED 2
‫ﻗﺑﻝ ﺃﻭﻝ ﺍﺳﺗﺧﺩﺍﻡ‬
‫ﺷﺣﻥ ﻣﺟﻣﻭﻋﺔ ﺍﻟﺑﻁﺎﺭﻳﺔ‬
‫ﺗﺣﺫﻳﺭ! ﺧﻁﺭ ﺍﻟﺗﻠﻑ‬
•
•
.‫ﻁﺎﻗﺔ ﺍﻟﺷﺣﻥ ﺇﻟﻰ 021 ﻭﺍﺕ‬
‫ﺍﻟﺗﺣﻘﻖ ﻣﻥ ﺣﺎﻟﺔ ﺍﻟﺷﺣﻥ‬
!‫ﻣﻼﺣﻅﺔ‬
•
•
LED 1
.1
.2
.3
.4
