5. Installation
5.1. Checks
− Check that the power unit is undamaged and that you have received the correct version.
− Check that the data on the packing slip correspond with the data shown on the product
received.
If you have any problems and/or in the case of ambiguity:
Please contact SIMCO or your regional agent.
5.2. Installation
5.2.1. Summary
Install the power unit in the position you like within the range of the connection leads of the
ionisation equipment.
Install the power unit in such a way that the switch and indicator lamp are clearly visible and
easily accessible.
It is recommended that the power unit is switched on/off via the machine.
Important:
− Make sure that the equipment is properly earthed. Earthing is needed to ensure proper
operation and to avoid electrical shocks upon contact.
5.2.2. Power unit mounting
Check that the voltage shown on the rating plate corresponds with the mains voltage.
− Attach the power unit using the fixing holes in the base plate.
− Lay the connection cable to the (mains) voltage connection.
− Connect the connection cable or fit a plug.
A-Unit 97.52.08.05.10
Brown (Black 1)
Bleu
(Black 2)
Green/Yellow
24
09/08
