Safety and operating instructions
F
B
A
G
TEX P60, P60S, P90, P90S
Air inlet
A.
B. Lubricator
Oil plug
C.
D. Handle
E. Silencer
Trigger (start and stop device)
F.
G. Tool retainer
Cylinder
H.
Labels
The machine is fitted with labels containing important
information about personal safety and machine
maintenance. The labels must be in such condition
that they are easy to read. New labels can be ordered
from the spare parts list.
Data plate
A
C
B
A. Machine type
Maximum permitted compressed air pressure
B.
Serial number
C.
14
C
D
E
H
D
E
© 2012 Atlas Copco Construction Tools AB | No. 9800 0650 90b | 2012-06-30
TEX 20PS, 21PE, 32P/PS, 33PE, 39P/PS, 40PE, P60/S,
The warning symbol together with the book
D.
symbol means that the user must read the
safety and operating instructions before the
machine is used for the first time.
E. The CE symbol means that the machine is
EC-approved. See the EC declaration which
is delivered with the machine for more
information. If the CE symbol is missing, it
means that the machine is not EC-approved.
Noise level label
WA
xxx
dB
The label indicates the guaranteed noise level
corresponding to EC-directive 2000/14/EC. See
"Technical data" for accurate noise level.
Safety label
To avoid injury, before using or servicing tool, read
and understand separately provided safety
instructions.
Installation
Hoses and connections
A
B
Compressed air source
A.
B. Water separator (optional)
Lubricator (optional)
C.
P90/S
D
C
Original instructions
