Dear MAC AUDIO Customer,
The APM 2.0 car hi-fi power amplifier will enable you to satisfy your high demands on sound reproduction in your
car. With its impressive deep-bass power reserves, low harmonic content and neutral reproduction, the APM 2.0
takes car hi-fi to new heights. The amplifier is characterized by low operating current, rapid switching capabilities
and excellent temperature stability. Increased output power can be achieved by switching two amplifier channels
in an amplifier together in bridging mode. Experience and enjoy how this high-tech machine perfectly reproduces
magnificent sound.
Please read all of the owner's manual before installing and using the amplifier.
1.

teCHniCAl DAtA

Max. output power (1 kHz sinus burst 2:8, B+=14.4V)
Nominal output power (DIN 45 324, B+=14.4V)
Max. output power (1 kHz sinus burst 2:8, B+=14.4V)
Nominal output power (DIN 45 324, B+=14.4V)
Loudspeaker impedance (stereo)
Frequency response
Total harmonic content (DIN 45 403)
Stereo separation (IEC 581 )
Weighted noise distance (IEC A)
Input sensitivity LOW LEVEL INPUT
Input impedance LOW LEVEL INPUT
Input sensitivity HIGH LEVEL INPUT
Input impedance HIGH LEVEL INPUT
Low-pass filter
High-pass filter
Bass boost
Supply
Fuse
Sizes (W x H x D)
Weight
suBJeCt tO teCHniCAl CHAnge
APM 2.0
2 x 150 W / 1 x 400 W
2 x 50 W / 1 x 130 W
2 x 200 W
2 x 65 W
2 – 8 Ohm
5 – 50 000 Hz (-3 dB)
< 0.08% (1 kHz)
> 60 dB (1 kHz)
> 100 dB
200 mV – 5 V
20 kOhm
0,8 - 12V
100 Ohm
50 – 250 Hz, 12 dB per octave
50 – 250 Hz, 12 dB per octave
0/6/12 dB at 45 Hz
+12 V (9 – 15 V), minus to ground
1 x 20 A
230 x 53 x 253 mm
1,65 kg
8
on 4 Ohm
on 4 Ohm
on 2 Ohm
on 2 Ohm
