5 Parts overview and scope of delivery

1
A
B
Illustration 1: Parts overview for base station (top) and remote sensor (bottom)
1 Display part for current time
3 Display part for weather data
5 MEM button (show recorded data)
7 DAY/NIGHT button
9 UP button (Value setting upwards)
11 Wall mount fixture
13 Stand, fold-out
15 Groove for mounting clip/stand
17 Battery compartment
Scope of delivery
Base station (A), remote sensor (B), mounting clip/stand (D)
12 / 20
2
3
15
14
16
15
9
4
5
6
7
8
2 ALARM ON/OFF touch button (turn off the
alarm)
4 CHANNEL button (channel selection)
6 TEST button
8 Battery compartment
10 DOWN button (Value setting downwards)
12 SET button (switch display and user spe-
cific settings)
14 Groove for mounting clip/stand
16 Battery compartment cover
18 Mounting clip/stand
