4. PRODUCT
DESCRIPTION
Minus button or
down/left button for
menu navigation.
Validation of temperature set point setting or accessing
4.1 LCD logo description:
1
Icon showing current operating mode
of thermostat with left to right:
Boost/timer mode
Auto mode
Comfort mode
Reduced / ECO mode
Frost protection mode
Off mode
2
Open window function
3
RF communication
Displaying of pilot wired order or
4
reduced auto mode,
order is applied to heating system
order of comfort minus 1 °C
order of comfort minus 2 °C
order of reduced set point or Auto
reduced mode
order of anti-freeze set point
order of stop
5
Measured temperature/ tem-
perature set point / remaining time for
boost mode.
2
3
5
1
to parameter menu or displaying measured
temperature/ temperature set point.
4
6
7
8
9
10
11
12
14
13
6
Locked keyboard.
7
Battery level.
8
Parameter menu number.
9
Parameter menu.
10
Indication of heating & cooling
demand
11
Unit for power consumption.
Type of measured data & sensor
12
used for system regulation:
•
Humidity measurement & control
•
Internal temperature sensor
•
Ambient temperature sensor
•
Floor temperature sensor
•
External temperature sensor
User derogation or "adaptive start"
13
during Auto mode application
Temperature units
14
measurement of humidity rate.
Plus button or up/
right button for
menu navigation.
or
or
