Parametric Eq. Types
(4 max per input)
(6 max per input)
High & Low pass output Crossover
Input Noise Gate (x8)
Input Compressor / Limiter (x8)
Input Frequency Shifter (x4)
(Feedback Loop Reducer)
Output Limiter (x8)
Built in Signal Generator
Mechanical
Dimensions (WxHxD)
Bypass / On-Off all channels
Param Eq. Freq: 20Hz-20kHz; Gain: -60/+12 dB; Q: 0.3 to 200
Low & High Shelf 6/12 dB/oct
Low & High Pass 6/12 dB/oct
All Pass 1/2 order
Bypass On-Off
filters (x8)
Butterworth in 6/12/18/24 dB/oct
Bessel in 12/18/24 dB/oct
Linkwitz-Riley in 12/24 dB/oct
Bypass On-Off
Threshold: from –80 dBV to +18 dBV
Depth: 0 dB to 80 dB
Attack time: from 0,1 ms. to 500 ms.
Hold time: from 10 ms. to 3000 ms.
Release time: from 10 ms. to 1000 ms.
Bypass On-Off
Threshold: from –36 dBV to +18 dBV
Ratio: 1:1 to inf:1 (limiter)
Knee: hard / soft
Attack time: from 0,1 ms. to 500 ms.
Release time: from 10 ms. to 1000 ms.
Make up gain: from 0 to +10 dB
Available on IN1 to IN4. ON / OFF function
Bypass On-Off
Threshold: from –36 dBV to +18 dBV
Attack time: from 0,1 ms. to 500 ms.
Release time: from 10 ms. to 1000 ms.
Sine: from 20 Hz to 20 kHz
Polarity: from 20 Hz to 20 kHz
White noise
Pink noise
Stereo Linking
Adjacent input / output channels
Linked processing
Matrix routing linked
Mix Matrix
Size: 8x8
Vol: Input, Output, Crosspoint
Mute: Set/Clear individual, row, column, all Input /output
Mono/stereo selector
Meter: Input /output VU and clip
Pager (x3)
Input: IN1 to IN8
Priorities: 3 (1 max, 3 min)
Depth: 0 dB to 80 dB
Attack time: from 5 ms. to 2000 ms.
Release time: from 50 ms. to 3000 ms.
Chime Source: None, Melody 1, Melody 2
Chime Volume: from –12 dB to 0 dB
482.6 x 44 x 253 mm / 19 x 1.73 x 9.96 in.
Weight
3.5kg
16
