Lamp replacement
Lamp replacement may be per-
formed in a "non-hazardous
area" only!
1. Unscrew the hexagon socket
screw and open the torch by
turning the bezel ring to the
left. Thereat, the light
aperture shall be directed
downwards (fig. 1/1a/1b).
2. The screw neck is screwed
off the bezel ring by turning
it left (fig. 3/3a).
3. Replace the bulb (fig. 3b).
4. Close the torch in inverse
order.
Mind!
Before screwing in the bezel
ring, apply a light coat of
vaseline to the thread (fig.
3c) (permanent smooth run-
ning of the bezel and of the
gasket).
When mounting the bezel ring,
take care that it is screwed in as
far as possible.
Also take care that while screw-
ing in the hexagon socket
screw, both holes on either side
of the hexagon socket screw
in the bezel ring are congruent
with the blind holes arranged
underneath in the enclosure.
Check the firm fit of the hexa-
gon socket screw.
Battery replacement
Battery replacement may
be performed in a "non-
hazardous area" only!
1. Unscrew the hexagon socket
screw and open the torch by
turning the bezel ring to the
left.
Thereat, the light aperture
shall be directed downwards
(fig. 1/1a/1b).
2. Take out the tube containing
the batteries (fig. 2).
3. Replace the dry batteries in
accordance with the marking
on the tube,
see fig. 2a.
4. Close the torch in inverse
order.
5. Entry in the control book,
where appropriate.
Mind:
Before screwing in the
bezel ring, apply a light
coat of vaseline to the thread
(fig. 3c) (permanent smooth
running of the bezel and of
the gasket).
When mounting the bezel
ring, take care that it is
screwed in as far as possible.
Also take care that while
screwing in the hexagon
socket screw, both holes on
either side of the hexagon
socket screw
in the bezel ring are congru-
ent with the blind holes ar-
ranged underneath in the en-
closure.
Recommendation: Always use
batteries of the same date of
manufacture.
Mind: Observe the proper
polarity when inserting
the dry batteries.
Note: Observe the national
regulations on waste disposal
when disposing of the batteries.
Subject to alteration or supple-
ment of the product series.
