1. Safety instructions

For skilled electricians and
trained personnel in
accordance with national
legislation, including the
relevant standards and,
where applicable, in acc.
with IEC 60079-17 on
electrical apparatus for
explosive atmospheres.
Observe the national safety
rules and regulations for
prevention of accidents as
well as the following safety
instructions which are
marked with an ( ) in
these operating instructions!
Note the special
conditions which are
named under No. 17 of
the enclosed EC type
examiation certificate.
The temperature class
marked on the portable
searchlight is to be
observed!
The portable searchlight
may only be opened or
charged outside of
"hazardous areas"!
Modifications to the lamp
or changes of its design
are not permitted!
The searchlight shall only
be used for its intended
purpose and in perfect
condition!
2. Conformity with
standards
This explosion protected
portable searchlight meets the
requirements of EN 50014, EN
50019, EN 50020, EN 60598, ,
the EC directive "Equipment
and protective systems
intended for use in potentially
explosive atmospheres" 94/9
EC and "Electromagnetic
compatibility" (89/336/EEC).
It has been designed,
manufactured and tested
according to the state of the art
and to EN 29001 (ISO 9001).
This portable searchlight is
suitable for use in zone 0, 1 and
2 hazardous areas acc. to
IEC 60079-10.

3. Technical data

Explosion
category: EEx ed ib IIC T4/T6
Category of
application: II 1 G
EC Type Examination
Certificate: PTB 99 A TEX 2197X
Approval of the
production quality
assurance: PTB 96
ATEX Q 001-1
lamp: PR6 2.5 V/0.3 A
Order No.: 2 2041 820 000
(5 pcs.)
Battery: 2 dry cells
T4: R20/LR20 IEC 86
T6: R20 IEC 86
Duration apx. 25 h
dep. on type of
battery
Permissible
ambient temperatures:
in general: -20°C to +40°C
Specified data kept at battery
temperature: -20°C to +30°C
Storage in original
packing: -40°C to +60°C
Protection category to
EN 60529
(IEC 60529): IP 65
Insulation class
to EN 60598: III
Dimensions
(mm): L200, Ø80
Weight: apx. 2.5 kg
