6.4 AC input switch
Maximum AC switch power
(protected by 30 A Thermal Circuit Breaker)
Switch-over time inverter to AC input
Switch-over time AC input to inverter (U batt >10,5 V)
Detection time AC input fault
Trip level mains to inverter
Trip level inverter to mains
Min. - Max. frequency range (50 Hz / 60 Hz)
1
Inverter runs parallel with the AC input.
6.5 Mechanical
12/800
/ 35
12/800
Cabinet
Color
Dimensions (HxWxD)
Weight (kg) 9
Battery-connection 1.5 m
cable
AC in/out Connection 2 * G-ST18i connector 2,5 mm
Start battery Terminals on printe board (connector suitable for 1mm
connection
External connection: Remote switch (connector for 3 wire Ø 1mm
sensing, Battery temperature sensor (connector for 2 wire Ø 1mm
remote switch Alarm: transistor, open collector 66 40mA (connector for 2 wire Ø 0,5 mm
Serial interface (UTP For Phoenix Remote Control
connector) For Mk. 1 with VEConfigure software
12/1200 12/1600 24/800
/ 50 / 70 / 16
12/1200 12/1600 24/800
Aluminum, protectin class IP21
375 mm x 215 mm x 115 mm (see App. A)
10 10 9
1.5m 1.5m 1.5m
2
6900 W
1
0 ms
1
0 ms
4 ms to 20 ms
180 VAC
187 VAC
45 – 55 Hz or 55 – 65 Hz
24/1200 24/1600
/ 25 / 40
24/1200 24/1600
Blue Ral 5012
10 10
1.5m 1.5m
2
wires)
2
)
2
)
48/1200 48/1600
/ 12 / 20
48/1200 48/1600
10 10
1.5m 1.5m
2
)
