P2.0 ORP SETTINGS
P3.0 COND SETTINGS
P4.0 TDS SETTING
P9.0 SETTINGS
Temperature measurement ATC – MTC
ATC : The direct measurement of the sample temperature for all parameters is carried out through

the NTC 30KΩ probe, which can be either integrated into the sensor (electrode and / or cell) or
external.
MTC : If no temperature probe is connected, the value must be changed manually:

keep pressed or
directional keys; then press

pH Parameter

pH 7 Vio; PC 7 Vio
On this series of devices, it is possible to use pH sensors with integrated temperature probe or to connect
two different sensors. Connect the pH electrode to the BNC type connector marked in green. Connect the
temperature probe to the RCA / CINCH Temp connector always marked with a green background.
The instrument is also able to recognize the DHS sensor, an innovative electrode that stores calibration
data and that can be used immediately after on any enabled instrument.
 pH parameter Setup
 In measure mode press
Press the button

 Move with the keys
UM Serie 7Vio EN rev.1 19.05.2020
P2.6
P2.8
P2.9
P3.1
P3.2
P3.3
P3.4
P3.6
P3.8
P3.9
P4.1
P9.1
P9.3
P9.4
P9.5
P9.6
P9.8
P9.9
until the value starts to flash; then adjust it by continuing to use the
to confirm.
to access the SETUP menu.
to access the pH SETTINGS P1.0 menu
and to select the program you want to access.
14
View ORP Cal
Reset ORP Setting
Temp Cal ORP
Cell Constant
Buffer Selection
Reference Temp
Temp. Compensation Factor
View Cond Cal
Reset Cond Setting
Temp. Cal Cond
TDS Factor
Temperature U.M.
Backlight mode
Brightness
Sleep Mode
Setup Parameters
Reset
Auto Power-Off
EN
