Symbols
Manufacturer
General symbol for recovery/ recyclable
Date of manufacture
Batch Code
Direct Current
o
55 C
Storage and Transportation Temperature Limit:
-25°C~55°C(-13°F~131°F)
o
-25 C
TYPE BF APPLIED PART
Refer to instruction manual/ booklet
106kPa
Atmospheric pressure limitation
70kP a
95%
Storage and Transportation Humidity limitation: 15%~95%RH
15%
Disposal of this product and used batteries should be
carried out in accordance with the national regulations for
the disposal of electronic products.
The first num.2:Protected against solid foreign objects of
12,5 mm and greater.The second num.2:Protection against
vertically falling water drops when ENCLOSURE tilted up to
15°
12
Calibration
The thermometer is initially calibrated at the time of manufacture. If
the thermometer is used according to the use instruction, periodic
recaliboration is not required. However, We recommend checking
calibration every two years or whenever clinical accuracy of the
thermometer is in question, Please send the complete device to the
dealer or manufacturer.The above recommendations do not
supersede the legal requirements. The user must always comply with
legal requirements for the control of the measurement, functionality,
and accuracy of the device which are required by the scope of
relevant laws, directives or ordinances where the device is used.
A clinical summary and procedures for checking calibration are
available upon request. (Turn on the thermometer and press the
button long time until entering into calibrate mode, software version
will be displayed.)
Battery Replacement
1. Replace battery when "
(See Figure 9)
2. Slide battery cover down as shown in Figure 10.
3. Remove battery and install 2 new AA alkaline batteries as shown in
Figure 11 .
4. Slide battery cover back on.
Figure 9
" appears at the buttom of LCD display.
Figure 10 Figure 11
