Fronius OPT/i TIG Installationsanleitung Seite 14

1 0
14
1 0
1 1
1 0
1 4
1 4
Insert the connection plate
9
Secure the connection plate using
10
1 0
8 TX25 screws
1 0
Tightening torque = 3 Nm
Fit the mains switch:
11
-
1 0
1 0
1 0
-
-
Secure the mains cable strain-reli-
12
ef device
Connect the cable to the gas sen-
13
sor
Cut off the gas hose at the height
14
of the notch
Use 2 TX20 screws to fit the
mains switch to the connection
plate
Position the switch knob
Fix the switch knob with a Phil-
lips screw
