Fronius OPT/i TIG Installationsanleitung Seite 12

Preparation
Preparation
1
2
Removing the right side panel
12
Switch off the power source and disconnect from the grid
iWave AC/DC
1
1
3
5
4
3
6 6
9
1
7x TX25
2
1
1
1
1
Remove the 8 TX25 screws
3
Remove the screw from the switch
4
3
knob using the Phillips® screwdri-
3
ver
Remove the switch knob
5
3
3
3
3
Remove the 2 TX20 screws from
6
the main switch
Loosen the mains cable strain-reli-
7
ef device
Fold out the connection plate
8
Slide the connection plate down
9
along the mains cable
iWave DC
1
1
2
1
1
5x TX25
1
