¡ The flexible metal pipe must not come into contact
with the moving parts of the unit in which the ap-
pliance is installed (e.g. a drawer) and must not
be routed through any spaces which might be-
come obstructed.
¡ Gas connection on the appliance: G 1/2.
Spare parts for gas connection
You can obtain the gas connection parts from the
technical customer service.
Connecting piece R 1/2"
Gas connection R 1/2
Fit the seal and the connecting piece R 1/2 to the
▶
gas connection on the appliance.
→ Fig.
8
Gas connection G 1/2
Insert the seal between the gas connection of the
▶
appliance and the gas supply.
→ Fig.
9
Electrical connection
¡ This appliance is type Y: The connection cable
must only be replaced by technical customer ser-
vice and not by the user. The cable type and the
minimum cross section must be respected.
¡ The hobs are supplied with a power cord with or
without a plug.
¡ Only connect appliances that are fitted with a plug
to a correctly installed socket with protective earth
conductor.
¡ If the plug is not accessible to the user, an all-pole
isolating safety switch with a minimum contact
opening of 3 mm must be provided.
→ Fig.
10
Converting the gas type
If the country's regulations allow, this appliance can
be adapted to other types of gas, if these are listed
on the rating plate.
You can find the right parts in the bag that is sup-
plied with the appliance or you can obtain them from
customer service. The table → Fig.
right combination for the relevant burner and gas
type.
Economy burner
Standard-output burner
High-output burner
Dual-wok multi-crown burner
¡ 1 - Outer flame
¡ 2 - Inner flame
Tools
Contact technical customer service to purchase the
relevant tools.
Removal lever
Adjusting the taps
Turn the rotary knobs to the minimum power posi-
1.
tion and pull them out.
With the tip of the screwdriver, push down on the
2.
flexible rubber holder to access the bypass screw.
→ Fig.
11
Never remove the sealing ring. The sealing rings
prevent liquids and dirt from finding their way into
the appliance and impairing its ability to function
properly.
3.
Removing the upper part of the appliance (glass
plate with cut-out profiles)
1.
00427950
2.
3.
4.
Replacing the nozzles
1.
2.
Replacing the outer flame nozzle on the multi-crown
burner
Requirement: The upper part of the appliance has
been removed. → "Removing the upper part of the
appliance (glass plate with cut-out profiles)",
Page 11
1.
2.
shows the
3.
23
4.
Replacing the inner flame nozzle on the multi-crown
burner
Requirement: The upper part of the appliance has
been removed. → "Removing the upper part of the
appliance (glass plate with cut-out profiles)",
Page 11
1.
483196
2.
3.
4.
Reinstalling the appliance
▶
When adjusting the bypass screws (M), refer to
the table → Fig. .
23
A: Firmly tighten the bypass screws.
‒
B: The bypass screws must be flush with the fit-
‒
ting.
→ Fig.
12
Remove the pan supports, burner caps, distribut-
ors and rotary knobs.
Undo the screws on the burners.
→ Fig.
13
Move the removal lever under the metal cut-out
profile into the area marked for the hob model
and loosen the front clip fastener.
→ Fig.
14
Only use the lever under the cut-out profiles or the
metal frame of the hob.
Carefully lift the glass plate with the cut-out pro-
files to release the rear clip fastener.
Remove all pan supports, burner caps and distrib-
utors.
Replace the nozzles using the appropriate wrench
and tighten them carefully to guarantee the seal.
→ Fig.
15
Ensure that the nozzle does not become detached
during removal or fastening.
To gain access to the main nozzle, loosen the
fastening screw and pull the sleeve
→ Fig.
16
Remove the nozzle by turning it anti-clockwise
and screw in the new outer flame nozzle
→ Fig.
17
Set the spacing of the adjustment sleeve for the
air supply to dimension Z, as shown in the table
→ Fig. .
23
→ Fig.
18
Tighten the fastening screw.
→ Fig.
19
Unscrew the tube by applying pressure to the
sleeve in the opposite direction to hold it in place
and pulling the tube out of the sleeve
→ Fig.
20
Remove the sleeve.
→ Fig.
21
Remove the inner flame nozzle from the sleeve
and screw in the new nozzle.
→ Fig.
22
Screw the sleeve and the tube back into their ori-
ginal position.
Install the appliance components in reverse order.
back.
⁠
⁠ .
⁠ .
