After successful installation and start of the software, you can scan the system
with the search setting PROFINET-Gerät. The PROmesh B8 compact is displayed
in the search result. You can then make and save individual entries in the
input mask.
! NOTE
Make sure that the IP address you selected has not yet been assigned. If re-
quired, you can display IP addresses that have already been assigned using the
PROscan® Active V2 license software from Indu-Sol.
! WARNING
When logging in for the first time, you must change the factory-set password.
It is your responsibility to document this password and protect it against
unauthorized access
Accessing the Web User Interface
The device-specific functions of the PROmesh B8 compact can be configured
via an integrated Web-UI. Open your browser, enter the IP address of the PRO-
mesh B8 compact configured in the ServiceTool in your browser bar or use the
above configuration data. Alternatively, you can right-click on the correspon-
ding list entry in the context menu of the ServiceTool to select „to website".
The Web UI now opens in your standard browser.
! NOTE
Further information on the configuration options and troubleshooting can be
found at the following link:
https://sdx.indu-sol.com/s/HiftDTLpYLbCEoS
16
ENGLISH
Interpreting LED Displays
LED label
VDC1
Status
Error
Port Status
Mode Meaning
Green Voltage at terminal sufficient
Off Voltage at terminal insufficient
Green Active connection to the PROFINET controller
Yellow No active connection to the PROFINET
controller
Red Power failure, port error or configured alarm
active
Off No power failure, no port error and no confi-
gured alarm active
On The port has established a valid network
connection
Flashing The port is in network communication
exchange
Off The port has not established a valid network
connection
