Mounting on the DIN Rail
Mount the PROmesh B8 compact upright in the switch cabinet on a 35 mm DIN
rail (DIN EN 60715).
! NOTE
The following distances to other modules must be observed:
•
right / left: 50 mm
•
top / bottom: 20 mm
! WARNING
Do not mount the PROmesh B8 compact directly next to devices that generate
strong electromagnetic interference fields or constantly emit heat to their
surroundings. Also protect the PROmesh B8 compact from intense sunlight.
Power Supply
The PROmesh B8 compact is operated with a voltage of 24 VDC, Connect a
suitable power source to the labeled terminals of the 3-pin 2,5 mm
block. Connect the positive lead to one of the VDC contacts and the ammuni-
tion lead to the corresponding GND contact.
If the external power supply is correctly connected and activated, all status
LEDs of the PROmesh B8 compact will light up briefly. After a short initializa-
tion phase the LEDs go out and the device is ready for operation and can now
be configured in the network.
14
ENGLISH
Configuring a Network Connection
Download the Service Tool to your client PC (Windows). You can find the soft-
ware at the following link:
https://sdx.indu-sol.com/s/HiftDTLpYLbCEoS
! NOTE
Our software is updated regularly. Please, make sure you are using the latest
version.
Connect the PC to a suitable data line on one of the data ports (P1 – 8).
The PROmesh B8 compact and the client PC must be located in the same IP
address range and IP subnet. For this you have to assign a corresponding
IP address to your PROmesh B8 compact for the first time. Use the already
installed ServiceTool.
After assigning a suitable IP address and subnet mask, the Web UI of the
PROmesh B8 compact can be reached.
terminal
2
The PROmesh B8 compact is delivered with the following factory settings:
IP Adress
Subnet mask
Gateway
Username
Password
0.0.0.0
0.0.0.0
0.0.0.0
admin
admin
ENGLISH
15
