Technical Data
Voltage Supply
Max. Current Consumption
Max. Power Consumption
Size (H x W x D)
Weight
Mounting
Protection Class
Storage temperature
Operating temperature
Relative Humidity
PROFINET Conformance
PROFINET standard
Port Mirroring
PROFINET Netload Class
Data Ports
Switching Mode
Diagnosis & Management
12
ENGLISH
24 VDC
0,8 A
8W
100 x 50 x 60 mm
350 g
35 mm DIN rail
IP20
-10°C ... 60°C
-10°C ... 60°C
5% .. 95%, RHD non-condensing
Class B
PROFINET 2.4
Rx, Tx+Rx
Class III
8x 10/100 MBit/s RJ45
Store & Forward
Network load monitoring
Port-Mirroring
DCP, I&M
SNMPv1, v2c, v3
General Information
The PROmesh B8 compact is a full-managed Ethernet/PROFINET switch for in-
dustrial automation systems which can be easily and conveniently configured
via a web UI. It enables uncomplicated installation of bus, star and ring struc-
tures with switching functionality.
Safety Instructions
Before putting the PROmesh B8 compact into operation, check whether it is in
perfect condition externally. Always observe the technical specifications of the
device to ensure safe and optimal use. The PROmesh B8 compact is designed
for IP20 protection environments. Take appropriate measures to ensure proper
operation of the unit in a different environment.
! WARNING
In case of suspected damage, please return the PROmesh B8 compact immedia-
tely to your supplier and do not put it into operation.
Do not open the housing under any circumstances. Unauthorized opening of
the housing will void any warranty claims.
The PROmesh B8 compact is designed for use in PROFINET applications accor-
ding to Conformance Class B.
For complete support of the PROFINET standards, please also observe the selec-
tion, layout and wiring of the data ports according to these standards.
• PROmesh B8 compact
• 3-pole 5 mm terminal block (power supply)
• Quickstart User Guide (hardcopy)
