1. Tablet.
2. Soporte tablet.
3. Pomos tablet.
4. Guarda trasera.
5. Enchufe alimentación.
6. Seta emergencia.
7. Bandeja viruta.
8. Luz led.
9. Display.
10. Soporte hta.
11. Guarda eje Z.
12. Carro Z.
13. Mordaza llave puntos.
14. Carro XY.
15. Guarda transparente.
16. Conector USB Tipo B.
17. Conector USB Tipo A. (Carga Tablet)
MÁQUINA ELECTRÓNICA ELECTRONIC MACHINE
1
4
11
12
8
13
14
5
3
1. Tablet.
2. Tablet stand.
3. Tablet knobs.
4. Rear guard shield.
5. Power plug.
6. Emergency stop button.
7. Swarf tray.
8. LED light.
9. Display.
10. HTA stand.
11. Z axis protective guard shield.
12. Z carriage assembly.
13. Dimple key clamp.
14. XY carriage assembly.
15. Transparent protective guard shield.
16. Type B USB connector.
17. Type A USB connector (tablet charging).
