MULTICODE NXT
8
9
10
11
12
18
19
1. Tablet.
2. Soporte tablet.
3. Pomos tablet.
4. Guarda trasera.
5. Enchufe alimentación.
6. Seta emergencia.
7. Bandeja viruta.
8. Luz led.
9. Display.
10. Soporte hta.
11. Fresa serreta.
12. Mordaza MP1.
13. Guarda eje Z.
14. Carro Z.
15. Mordaza llave puntos.
16. Carro XY.
17. Guarda transparente.
18. Conector USB Tipo B.
19. Conector USB Tipo A (Carga Tablet)
1
13
4
14
8
15
16
3
1. Tablet.
2. Tablet stand.
3. Tablet knobs.
4. Rear guard shield.
5. Power plug.
6. Emergency stop button.
7. Swarf tray.
8. LED light.
9. Display.
10. HTA stand.
11. Cylinder cutter.
12. MP1 clamp.
13. Z axis protective guard shield.
14. Z carriage assembly.
15. Dimple key clamp.
16. XY carriage assembly.
17. Transparent protective guard shield.
18. Type B USB connector.
19. Type A USB connector (tablet charging)
2
17
5
15
ES / EN
7
