Meter Report Command: [Command Class Meter， Meter Report，scale(bit 2) +Rate Type + Meter
Type， Precision + Scale(bit 1,0)+ Size，Meter Value 1，Meter Value 2]
Meter Get Command: [Command Class Meter, Meter Get, Scale =0x05(I)]
Meter Report Command: [Command Class Meter， Meter Report，scale(bit 2) +Rate Type +Meter Type，
Precision + Scale(bit 1,0)+ Size，Meter Value 1，Meter Value 2]
Rate Type = 0x01
Meter Type = 0x01
Precision = 2
Scale = 0x05(I)
Size = 2 Bytes (Meter Value)
Meter Value 1 = High Byte (I)
Meter Value 2 = Low Byte (I)
Beispiel:
Scale = 0x05 (I)
Precision = 2
Size = 2 (2 Bytes of I)
Meter Value 1 = 0x01(I)
Meter Value 2 = 0x21(I)
Wechselstrom = (Meter Value 1*256) +(Meter Value 2)= 2.89 (A)
2-2-6 Nutzleistung (PF)
Wenn die Home Control Schalt- und Messsteckdose Meter Get Command empfängt, meldet sie Meter
Report Command an die Node ID.
Meter Get Command: [Command Class Meter, Meter Get, Scale =0x06(PF)]
Meter Report Command: [Command Class Meter，Meter Report，scale(bit 2) +Rate Type + Meter Type,
Precision + Scale(bit 1,0)+ Size，Meter Value 1]
Rate Type = 0x01
Meter Type = 0x01
Precision = 2
Scale = 0x06(PF)
Size = 1 Bytes
Meter Value 1
Beispiel:
Scale = 0x06 (PF)
Precision = 2
Size = 1 (1 Byte of PF)
Meter Value 1 = 0x63(PF)
Nutzleistung (PF) = Meter Value 1 =0.99
