Storage holder (14)
Put the vacuum cleaner and accessories in the
provided storage holder (14) on the wall.
Installation and assembly of the storage holder
(Fig. E)
1. Drill holes on the designated position in the
wall.
2. Mount the storage holder (14), with UP Arrow
pointing up. Mount the storage holder with
screws and plugs firmly.
3. Slide the nozzle holder in the slot until it
clamped tight.
4. Store accessories in the nozzle holder.
5. Slide vacuum cleaner with bottom side to
storage holder until the machine is locked in
place (Fig. F).
4. OPERATION
Note: Regular emptying of the dust cup and
cleaning of the filter assembly ensures optimal
vacuum capacity.
Switching on and off (Fig. A)
• To switch on the machine, slide the on/off
switch (2) to the front.
• To switch off the machine, slide the on/off
switch (2) to the rear.
5. MAINTENANCE
Before cleaning and maintenance, always
switch off the machine and remove the
battery pack from the machine.
Clean the machine casings regularly with a soft
cloth, preferably after each use. Make sure that
the ventilation openings are free of dust and
dirt. Remove very persistent dirt using a soft
cloth moistened with soapsuds. Do not use any
solvents such as gasoline, alcohol, ammonia,
etc. Chemicals such as these will damage the
synthetic components.
Cleaning the Dust Cup (Fig. C)
To maintain the optimum performance of the
vacuum cleaner, clean the dust cup (7) after each
use.
12
• Press the release button (3) and remove the
dust cup (7) from the motor housing (6).
• Shake/tap out the dust cup over a suitable
waste bin. If required, clean the dust cup with
a moist cloth. If required, clean the HEPA filter
(See "Cleaning the HEPA filter").
• Reinsert the HEPA filter (16) into the dust cup (7).
• Afterwards, hang the dust cup at the bottom
into the motor housing, apply light pressure
until the dust cup can be heard engage.
Cleaning the HEPA filter (Fig. D)
• Press the release button (3) and remove the
dust cup (7) from the motor housing (6).
• Remove the HEPA filter (16) from the motor
housing by twisting the filter clockwise.
• Shake/tap the filter over a suitable waste
bin. If necessary, you can wet clean the filter
(16): Clean it under running water without any
cleaning detergent, shake/tap the filter as dry
as possible and allow the filter to dry 24 hours
in order to avoid the formation of mould.
• Assembly is carried out in reverse order.
MALFUNCTIONS
In the case of insufficient vacuuming
performance, check the following:
1. Is the dust cup (7) full?
• See "Cleaning the Dust Cup".
2. Is the HEPA filer (16) clogged with dust?
• See "Cleaning the HEPA filter".
3. Is the capacity of the batter pack to low?
• Make sure the battery pack is charged fully
for optimum suction capacity.
Regular emptying of the dust cup (7) and cleaning
of the HEPA filter (16) ensures optimal vacuum
capacity.
ENVIRONMENT
Faulty and/or discarded electrical or
electronic apparatus have to be collected
at the appropriate recycling locations.
Only for EC countries
Do not dispose of power tools into domestic
waste. According to the European Guideline
2012/19/EC for Waste Electrical and Electronic
